MAX13046EELT+T

Active

Analog Devices Inc./Maxim Integrated

IC TRANSLTR BIDIRECTIONAL 6UDFN

Search across all available documentation for this part.

Active

Analog Devices Inc./Maxim Integrated

IC TRANSLTR BIDIRECTIONAL 6UDFN

Technical Specifications

Parameters and characteristics for this part

Specification	MAX13046EELT+T

Channel Type	Bidirectional
Channels per Circuit	1
Data Rate	16 MBd
Features	Thermal-Shutdown Protection
Mounting Type	Surface Mount
Number of Circuits	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Output Type	Push-Pull
Package / Case	6-WFDFN
Supplier Device Package	6-µDFN (1.5x1)
Translator Type	Voltage Level
Voltage - VCCA [Max]	3.6 V
Voltage - VCCA [Min]	1.1 V
Voltage - VCCB [Max]	5.5 V
Voltage - VCCB [Min]	1.65 V

IC TRANSLTR BIDIRECTIONAL 6UDFN

Part	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - VCCA [Max]	Voltage - VCCA [Min]	Features	Supplier Device Package	Number of Circuits	Output Type	Package / Case	Channel Type	Data Rate	Voltage - VCCB [Min]	Voltage - VCCB [Max]	Translator Type	Channels per Circuit
Analog Devices Inc./Maxim Integrated MAX13046EELT+T	Surface Mount	85 °C	-40 °C	3.6 V	1.1 V	Thermal-Shutdown Protection	6-µDFN (1.5x1)	1	Push-Pull	6-WFDFN	Bidirectional	16 MBd	1.65 V	5.5 V	Voltage Level	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Voltage Level Translator Bidirectional 1 Circuit 1 Channel 16Mbps 6-µDFN (1.5x1)
