ABB-03PMFS-LC7001

Active

Amphenol LTW

STANDARD STAMPING PIN

Search across all available documentation for this part.

Active

Amphenol LTW

STANDARD STAMPING PIN

Technical Specifications

Parameters and characteristics for this part

Specification	ABB-03PMFS-LC7001

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	10 A
Fastening Type	Bayonet Lock
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Front Side Nut
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Finish	Nickel
Shell Size - Insert	B
Shielding	Unshielded
Voltage Rating	300 VDC

Part	Ingress Protection	Insert Material	Contact Material	Shell Size - Insert	Orientation	Color	Voltage Rating	Shell Finish	Shielding	Current Rating (Amps)	Connector Type	Primary Material	Material Flammability Rating	Mounting Feature	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Fastening Type
Amphenol LTW ABB-03PMFS-SC7001	IP67 - Dust Tight Waterproof	Polyamide (PA) Nylon Glass Filled	Copper Alloy	B	Keyed	Black	300 VDC	Nickel	Unshielded	10 A	Receptacle Female Sockets	Plastic	UL94 V-0	Bulkhead - Front Side Nut	-40 °C	105 ░C	Gold
Amphenol LTW ABB-03PMFS-LC7001	IP67 - Dust Tight Waterproof	Polyamide (PA) Nylon Glass Filled	Copper Alloy	B	Keyed	Black	300 VDC	Nickel	Unshielded	10 A	Receptacle Female Sockets	Plastic	UL94 V-0	Bulkhead - Front Side Nut	-40 °C	105 ░C	Gold	Bayonet Lock

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Circular Connector Receptacle, Female Sockets Solder Cup
