858VA04-203RLU4

Active

MH Connectors

CONN PLUG FMALE 4P GOLD SLDR CUP

Search across all available documentation for this part.

Active

MH Connectors

CONN PLUG FMALE 4P GOLD SLDR CUP

Technical Specifications

Parameters and characteristics for this part

Specification	858VA04-203RLU4

Color	Black, Silver
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	10 çin
Contact Finish Thickness - Mating	0.25 çm
Contact Material	Brass
Current Rating (Amps)	4 A
Features	Coupling Nut
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA66), Nylon 6/6
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	4
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	A
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Brass
Shell Size - Insert	M12-4
Shielding	Unshielded
Voltage Rating	250 VDC

Part	Current Rating (Amps)	Contact Material	Shielding	Connector Type	Shell Finish	Shell Material	Ingress Protection	Number of Positions	Insert Material	Material Flammability Rating	Voltage Rating	Shell Size - Insert	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Mounting Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Orientation	Color	Primary Material	Features
MH Connectors 858VA04-103RLU4	4 A	Brass	Unshielded	Male Pins Receptacle	Nickel	Brass	IP67 - Dust Tight Waterproof	4	Polyamide (PA66) Nylon 6/6	UL94 V-0	250 VDC	M12-4	-40 °C	105 ░C	Gold	Free Hanging (In-Line)	10 çin	0.25 çm	A	Black Silver	Metal
MH Connectors 858VA04-203RLU4	4 A	Brass	Unshielded	Female Sockets Plug	Nickel	Brass	IP67 - Dust Tight Waterproof	4	Polyamide (PA66) Nylon 6/6	UL94 V-0	250 VDC	M12-4	-40 °C	105 ░C	Gold	Free Hanging (In-Line)	10 çin	0.25 çm	A	Black Silver	Metal	Coupling Nut

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	100	$ 10.66

General part information

4 Position Circular Connector Plug, Female Sockets Solder Cup
