PWM-90-36

Active

MEAN WELL USA Inc.

LED DRIVER CV AC/DC 36V 2.5A

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

LED DRIVER CV AC/DC 36V 2.5A

Technical Specifications

Parameters and characteristics for this part

Part	Features	Dimming	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Termination Style	Efficiency	Type	Ratings	Voltage - Output	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Voltage - Input (Max) [Max]	Approval Agency	Mounting Type	Voltage - Isolation	Power (Watts)	Voltage - Input (Min) [Min]	Current - Output (Max) [Max]	Topology	Standard Number
MEAN WELL USA Inc. PWM-90-24	OCP OTP OVP SCP	Analog PWM	2.48 in	63 mm	171 mm	37.5 mm	1.48 "	6.73 in	Wire Leads	90.5 %	Constant Voltage	IP67	24 V	85 °C	-40 °C	1	305 VAC	CB CCC CE cURus ENEC	Chassis Mount	3750 V	90 W	90 VAC	3.75 A	AC DC Converter
MEAN WELL USA Inc. PWM-90-12DA	OCP OTP OVP SCP	Analog PWM	2.48 in	63 mm	171 mm	37.5 mm	1.48 "	6.73 in	Wire Leads	88 %	Constant Voltage	IP67	12 V	85 °C	-40 °C	1	305 VAC	CB CCC CE cURus EAC ENEC	Chassis Mount	3750 V	90 W	90 VAC	1.88 A	AC DC Converter	UL 8750
MEAN WELL USA Inc. PWM-90-36	OCP OTP OVP SCP	Analog PWM	2.48 in	63 mm	171 mm	37.5 mm	1.48 "	6.73 in	Wire Leads	90.5 %	Constant Voltage	IP67	36 V	85 °C	-40 °C	1	305 VAC	CB CCC CE cURus ENEC	Chassis Mount	3750 V	90 W	90 VAC	2.5 A	AC DC Converter

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	18	$ 37.25

General part information

2.5A 36V Constant Voltage LED Driver AC DC Converter Topology 1 Output

Technical documentation and resources

No documents available
