H2C0.38BK
ActiveTechflex
HEATSHRINK 3/8" X 4' BLACK
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
H2C0.38BK
ActiveTechflex
HEATSHRINK 3/8" X 4' BLACK
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | H2C0.38BK |
|---|---|
| Color | Black |
| Features | Fluid Resistant, Flame Retardant |
| Inner Diameter - Recovered [diameter] | 4.75 mm |
| Inner Diameter - Recovered [diameter] | 0.187 in |
| Inner Diameter - Supplied [diameter] | 0.375 in |
| Inner Diameter - Supplied [diameter] | 9.53 mm |
| Length [x] | 1.22 m |
| Length [x] | 4 ft |
| Material | Polyolefin (PO) |
| Operating Temperature [Max] | 135 °C |
| Operating Temperature [Min] | -55 °C |
| Recovered Wall Thickness [custom] | 0.025 " |
| Recovered Wall Thickness [custom] | 0.64 mm |
| Shelf Life | 144 Months |
| Shrinkage Ratio | 2 to 1 |
| Type | Tubing, Flexible |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 51.08 | |
| 2 | $ 46.98 | |||
| 3 | $ 44.74 | |||
| 5 | $ 42.06 | |||
| 7 | $ 40.38 | |||
| 10 | $ 38.68 | |||
| 25 | $ 34.63 | |||
| 50 | $ 33.90 | |||
Description
General part information
H2C0 Series
Heat Shrink Tubing, Flexible 0.375" (9.53mm) 2 to 1 Black 4.00' (1.22m)
