HDT44-PR
ActiveAdam Tech
CONN D-SUB HD HOUSING PLUG 44POS
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | HDT44-PR |
|---|---|
| Color | Black |
| Connector Style | High Density, D-Sub |
| Connector Type | Plug for Male Contacts |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Features | Grounding Indents |
| Flange Feature | Housing/Shell (Unthreaded) |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 44 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -65 ░C |
| Shell Size, Connector Layout [custom] | B, DB |
| Shell Size, Connector Layout [x] | 3 |
HDT44 Series
| Part | Mounting Type | Material Flammability Rating | Contact Material | Dielectric Material | Color | Number of Rows | Number of Positions | Flange Feature | Connector Style | Current Rating (Amps) | Contact Finish | Connector Type | Shell Size, Connector Layout [x] | Shell Size, Connector Layout [custom] | Voltage Rating | Contact Finish Thickness | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Adam Tech | Free Hanging (In-Line) | UL94 V-0 | Copper Alloy | Polybutylene Terephthalate (PBT) Glass Filled | Black | 3 | 44 | Housing/Shell (Unthreaded) | D-Sub High Density | 3 A | Gold | Receptacle Female Sockets | 3 | B DB | 250 VAC | |||||
Adam Tech | Through Hole | UL94 V-0 | Copper Alloy | Polybutylene Terephthalate (PBT) Glass Filled | Black | 3 | 44 | Housing/Shell (Unthreaded) | D-Sub High Density | 3 A | Gold | Receptacle Female Sockets | 3 | B DB | 250 VAC | Flash | Solder | |||
Adam Tech | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Glass Filled | Black | 44 | Housing/Shell (Unthreaded) | D-Sub High Density | Receptacle Female Sockets | 3 | B DB | |||||||||||
Adam Tech | Free Hanging (In-Line) | UL94 V-0 | Phosphor Bronze | Polybutylene Terephthalate (PBT) Glass Filled | Black | 3 | 44 | Female Screwlock (4-40) Mating Side | D-Sub High Density | 5 A | Gold | Receptacle Female Sockets | 3 | B DB | 250 VAC | Flash | 125 °C | -65 ░C | ||
Adam Tech | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Glass Filled | Black | 44 | Housing/Shell (Unthreaded) | D-Sub High Density | Plug for Male Contacts | 3 | B DB | 125 °C | -65 ░C | Grounding Indents |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 3.69 | |
| 10 | $ 2.82 | |||
| 25 | $ 2.54 | |||
| 40 | $ 2.41 | |||
| 80 | $ 2.23 | |||
| 230 | $ 1.99 | |||
| 440 | $ 1.86 | |||
| 945 | $ 1.72 | |||
| 2400 | $ 1.57 | |||
Description
General part information
HDT44 Series
Plug for Male Contacts Housing D-Sub, High Density Connector 44 Position
