AM1A-4805SZ

Active

aimtec

DC DC CONVERTER 5V 1W

Search across all available documentation for this part.

Active

aimtec

DC DC CONVERTER 5V 1W

Technical Specifications

Parameters and characteristics for this part

DC DC CONVERTER 5V 1W

Part	Voltage - Isolation	Approval Agency	Number of Outputs	Voltage - Output 1	Voltage - Input (Min) [Min]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Type	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Max) [Max]	Package / Case	Efficiency	Applications	Mounting Type
aimtec AM1A-4805SZ	1.5 kV	CE, cURus, UL	1	5 V	36 V	11 mm	17 mm	0.3 "	7.6 mm	0.43 "	0.67 in	Isolated Module	200 mA	85 °C	-40 °C	75 V	6-SIP Module	76 %	ITE (Commercial)	Through Hole

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 5V 200mA 36V - 75V Input
