8-1971817-5
ActiveTE Connectivity AMP Connectors
5P,RAST 2.5 TAB HEADER,EX- LOCKING,THV
8-1971817-5
ActiveTE Connectivity AMP Connectors
5P,RAST 2.5 TAB HEADER,EX- LOCKING,THV
Description
General part information
1971817 Series
PCB Mount Header, Vertical, Wire-to-Board, 5 Position, 2.5 mm [.098 in] Centerline, Fully Shrouded, Tin (Sn), Through Hole - Solder, Signal, Natural
Technical Specifications
Parameters and characteristics for this part
| Specification | 8-1971817-5 |
|---|---|
| Connector Type | Header |
| Contact Finish - Mating | Tin |
| Contact Finish - Post | Tin |
| Contact Length - Post | 0.114 in |
| Contact Material | Copper Alloy |
| Contact Shape | Square |
| Contact Type | Tab |
| Current Rating | 6 A |
| Fastening Type | Locking Ramp |
| Features | Board Guide |
| Insulation Color | Natural |
| Insulation Height | 0.61 in |
| Insulation Material | Nylon, Polyamide (PA) |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 5 |
| Number of Positions Loaded | All |
| Number of Rows | 1 |
| Operating Temperature (Max) | 120 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch - Mating | 0.098 in |
| Shrouding | Shrouded - 4 Wall |
| Style | Cable/Wire, Board |
| Termination | Solder |
| Voltage Rating (AC) | 250 VAC, 50 VAC |
