4612X-102-562LF

Active

Bourns Inc.

RES ARRAY 6 RES 5.6K OHM 12SIP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

4612X-102-562LF

Active

Bourns Inc.

RES ARRAY 6 RES 5.6K OHM 12SIP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	4612X-102-562LF

Circuit Type	Isolated
Height - Seated (Max) [Max] [z]	5.08 mm
Height - Seated (Max) [Max] [z]	0.2 "
Mounting Type	Through Hole
Number of Pins	12
Number of Resistors	6
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	12-SIP
Power Per Element	300 mW
Resistance (Ohms)	5.6 kOhms
Size / Dimension [x]	1.198 in
Size / Dimension [x]	30.43 mm
Size / Dimension [y]	2.49 mm
Size / Dimension [y]	0.098 in
Supplier Device Package	12-SIP
Temperature Coefficient	100 ppm/°C
Tolerance	2 %

4612X Series

Part	Power Per Element	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Number of Pins	Number of Resistors	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Operating Temperature [Min]	Operating Temperature [Max]	Circuit Type	Resistance (Ohms)	Tolerance	Temperature Coefficient	Supplier Device Package	Mounting Type	Package / Case	Resistance (Ohms)
Bourns Inc. 4612X-102-123LF	300 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	6	5.08 mm	0.2 "	-55 °C	125 °C	Isolated	12 kOhms	2 %	100 ppm/°C	12-SIP	Through Hole	12-SIP
Bourns Inc. 4612X-102-562LF	300 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	6	5.08 mm	0.2 "	-55 °C	125 °C	Isolated	5.6 kOhms	2 %	100 ppm/°C	12-SIP	Through Hole	12-SIP
Bourns Inc. 4612X-101-102LF	200 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	11	5.08 mm	0.2 "	-55 °C	125 °C	Bussed	1 kOhms	2 %	100 ppm/°C	12-SIP	Through Hole	12-SIP
Bourns Inc. 4612X-101-152LF	200 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	11	5.08 mm	0.2 "	-55 °C	125 °C	Bussed	1.5 kOhms	2 %	100 ppm/°C	12-SIP	Through Hole	12-SIP
Bourns Inc. 4612X-102-472LF	300 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	6	5.08 mm	0.2 "	-55 °C	125 °C	Isolated		2 %	100 ppm/°C	12-SIP	Through Hole	12-SIP	4.7k
Bourns Inc. 4612X-102-561LF	300 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	6	5.08 mm	0.2 "	-55 °C	125 °C	Isolated	560 Ohms	2 %	100 ppm/°C	12-SIP	Through Hole	12-SIP
Bourns Inc. 4612X-101-104LF	200 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	11	5.08 mm	0.2 "	-55 °C	125 °C	Bussed	100 kOhms	2 %	100 ppm/°C	12-SIP	Through Hole	12-SIP
Bourns Inc. 4612X-102-331LF	300 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	6	5.08 mm	0.2 "	-55 °C	125 °C	Isolated	330 Ohms	2 %	100 ppm/°C	12-SIP	Through Hole	12-SIP
Bourns Inc. 4612X-102-105LF	300 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	6	5.08 mm	0.2 "	-55 °C	125 °C	Isolated		2 %	100 ppm/°C	12-SIP	Through Hole	12-SIP	1M
Bourns Inc. 4612X-102-470LF	300 mW	2.49 mm	1.198 in	0.098 in	30.43 mm	12	6	5.08 mm	0.2 "	-55 °C	125 °C	Isolated	47 Ohms	1 Ohm	250 ppm/°C	12-SIP	Through Hole	12-SIP

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	2000	$ 0.13

Description

General part information

4612X Series

5.6k Ohm ±2% 300mW Power Per Element Isolated 6 Resistor Network/Array ±100ppm/°C 12-SIP
