AM3D-0512DZ
Activeaimtec
DC DC CONVERTER +/-12V 3W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AM3D-0512DZ
Activeaimtec
DC DC CONVERTER +/-12V 3W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM3D-0512DZ |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output (Max) | 125 mA |
| Current - Output (Max) | 125 mA |
| Efficiency | 84 % |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 3 W |
| Size / Dimension [x] | 19.5 mm |
| Size / Dimension [x] | 0.77 in |
| Size / Dimension [y] | 0.28 in |
| Size / Dimension [y] | 7.2 mm |
| Size / Dimension [z] | 0.39 in |
| Size / Dimension [z] | 10 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 5.5 V |
| Voltage - Input (Min) [Min] | 4.5 V |
| Voltage - Isolation | 1000 V |
| Voltage - Output 1 [Max] | 12 V |
| Voltage - Output 1 [Min] | -12 V |
| Voltage - Output 2 | -12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 7.30 | |
| 10 | $ 6.42 | |||
| 25 | $ 6.10 | |||
| 50 | $ 5.86 | |||
| 100 | $ 5.64 | |||
| 250 | $ 5.36 | |||
| 500 | $ 5.15 | |||
| 1000 | $ 4.96 | |||
Description
General part information
AM3D Series
Isolated Module DC DC Converter 2 Output -12 ~ 12V -12V 125mA, 125mA 4.5V - 5.5V Input
