AB-FC01230-19712-8A1

Active

American Bright Optoelectronics Corporation

LED MOD AB-FC WH LNR STRP 3000K

Search across all available documentation for this part.

Active

American Bright Optoelectronics Corporation

LED MOD AB-FC WH LNR STRP 3000K

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Lighting COBs Engines Modules LED Module AB-FC White, Warm Linear Light Strip, Flexible

Technical documentation and resources

Specification	AB-FC01230-19712-8A1	AB-FC01230 Series

Color	White, Warm	White, Warm
Configuration	Linear Light Strip, Flexible	Linear Light Strip, Flexible
CRI (Color Rendering Index)	80	80
Current - Test	660 mA	660 mA
Features	IP65	IP65
Height [z]	2.5 mm	2.5 mm
Lens Type	Flat	Flat
Lumens/Watt @ Current - Test	91 lm/W	46 - 91 lm/W
Luminous Flux @ Current/Temperature	720 lm	334 - 720 lm
Size / Dimension	-	25 mm
Size / Dimension [x]	5000 mm	5000 mm
Size / Dimension [y]	10 mm	10 mm
Type	LED Module	LED Module
Viewing Angle	120 °	120 °
Voltage - Forward (Vf) (Typ)	12 V	12 V

Part	Viewing Angle	Lens Type	Configuration	Size / Dimension [x]	Size / Dimension [y]	Color	CRI (Color Rendering Index)	Luminous Flux @ Current/Temperature	Type	Features	Current - Test	Lumens/Watt @ Current - Test	Height [z]	Voltage - Forward (Vf) (Typ)	Size / Dimension [custom]
American Bright Optoelectronics Corporation AB-FC01230-19712-8A1	120 °	Flat	Flexible, Linear Light Strip	5000 mm	10 mm	Warm, White	80	720 lm	LED Module	IP65	660 mA	91 lm/W	2.5 mm	12 V
American Bright Optoelectronics Corporation AB-FC01230-19700-8A1	120 °	Flat	Flexible, Linear Light Strip	5000 mm	10 mm	Warm, White	80	334 lm	LED Module	IP65	660 mA	46 lm/W	2.5 mm	12 V	25 mm
