GFX-AE8860F16-5K

Active

Advantech Corp

E8860 2G DDR5 PCI-EX16 4*DP FULL

Search across all available documentation for this part.

Active

Advantech Corp

E8860 2G DDR5 PCI-EX16 4*DP FULL

Technical Specifications

Parameters and characteristics for this part

Specification	GFX-AE8860F16-5K

Cooling Type	Fansink
Expansion Site/Bus	PCI Express
Form Factor	PCIe
Function	PCIe Based Graphic Expansion Card
Power (Watts)	46 W
Size / Dimension [x]	5.708 in
Size / Dimension [x]	145 mm
Size / Dimension [y]	111 mm
Size / Dimension [y]	4.37 "
Video Outputs	DisplayPort, HDMI, DVI

Part	Power (Watts)	Video Outputs	Function	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Expansion Site/Bus	Cooling Type	Form Factor
Advantech Corp GFX-AE8860N16-5M	51 W	DisplayPort DVI HDMI	E8860 PCIe Add-In Board	82 mm	3.238 in	79 mm	3.11 "
Advantech Corp GFX-AE8860F16-5K	46 W	DisplayPort DVI HDMI	PCIe Based Graphic Expansion Card	145 mm	5.708 in	111 mm	4.37 "	PCI Express	Fansink	PCIe

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

E8860 2G DDR5 PCI-EX16 4*DP FULL
