ZXFV302EV

Active

Diodes Inc

EVAL BOARD FOR ZXFV302

Search across all available documentation for this part.

Active

Diodes Inc

EVAL BOARD FOR ZXFV302

Technical Specifications

Parameters and characteristics for this part

Part	Number of Circuits	Supplier Device Package	Switch Circuit	Package / Case	Package / Case [x]	Package / Case [y]	Voltage - Supply, Dual (V±) [Min]	Voltage - Supply, Dual (V±) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Multiplexer/Demultiplexer Circuit	-3db Bandwidth	Voltage - Supply, Single (V+) [Max]	Voltage - Supply, Single (V+) [Min]	Crosstalk	Switch Time (Ton, Toff) (Max) [custom]	Switch Time (Ton, Toff) (Max) [custom]	Function	Supplied Contents	Type	Embedded	Primary Attributes
Diodes Inc ZXFV302N16TC	1	16-SO	SP4T	16-SOIC	0.154 in	3.9 mm	-4.75 V	5.25 V	85 °C	-40 °C	Surface Mount	4:1	300 MHz	5.25 V	4.75 V	-75 dB	10 ns	35 ns
Diodes Inc ZXFV302EV																			Video Multiplexer	Board(s)	Video		4:1 Video Multiplexer

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	N/A	1	$ 69.54

General part information

ZXFV302 Video Multiplexer Video Evaluation Board

Technical documentation and resources
