TRAB24-49003
ActiveTE Connectivity Raychem Cable Protection
RF ANT 2.4GHZ/4.9GHZ DOME NMO
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TRAB24-49003
ActiveTE Connectivity Raychem Cable Protection
RF ANT 2.4GHZ/4.9GHZ DOME NMO
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TRAB24-49003 |
|---|---|
| Antenna Type | Dome |
| Applications | WLAN |
| Frequency (Center/Band) | 4.9 GHz, 2.4 GHz |
| Frequency Group | 4 GHz |
| Frequency Group [Max] | 3 GHz |
| Frequency Group [Min] | 2 GHz |
| Frequency Range [Max] | 5.85 GHz, 2.5 GHz |
| Frequency Range [Min] | 4.9 GHz, 2.4 GHz |
| Gain | 0.7 dBi, 0.6 dBi |
| Height (Max) | 2.299 in |
| Height (Max) | 58.4 mm |
| Mounting Type | Base Mount |
| Number of Bands | 2 |
| Power - Max [Max] | 100 W |
| RF Family/Standard | WiFi |
| Termination | NMO |
| VSWR | 2, 3 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 50.84 | |
| 10 | $ 47.76 | |||
| 25 | $ 46.22 | |||
| 100 | $ 42.83 | |||
Description
General part information
TRAB24 Series
RF ANTENNA WLAN Dome NMO Base Mount
