DS2710EVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT DS2710 (SINGLE-CELL NIM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
DS2710EVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT DS2710 (SINGLE-CELL NIM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DS2710EVKIT+ | DS2710 Series |
|---|---|---|
| Battery Chemistry | - | Nickel Metal Hydride |
| Embedded | False | False |
| Function | Battery Charger | Battery Charger |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 1 |
| Operating Temperature | - | 70 °C |
| Operating Temperature | - | -20 °C |
| Package / Case | - | 10-WFDFN Exposed Pad |
| Primary Attributes | Overvoltage Protection | Overvoltage Protection |
| Programmable Features | - | Timer |
| Secondary Attributes | Safety Timer, Thermal Protection, Recharge, Automatic Charge Termination | Safety Timer, Thermal Protection, Recharge, Automatic Charge Termination |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 10-TDFN (3x4) |
| Type | Power Management | Power Management |
| Utilized IC / Part | DS2710 | DS2710 |
| Voltage - Supply (Max) | - | 5.5 V |
