AM2GH-1205SZ

Unknown

aimtec

MODULE DC-DC 12VIN 1-OUT 5V 0.4A 2W 7-PIN SIP TUBE

Search across all available documentation for this part.

Unknown

aimtec

MODULE DC-DC 12VIN 1-OUT 5V 0.4A 2W 7-PIN SIP TUBE

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 5V 400mA 4.5V - 18V Input

Technical documentation and resources

Parameters and characteristics commom to parts in this series

MODULE DC-DC 12VIN 1-OUT 5V 0.4A 2W 7-PIN SIP TUBE

Part	Approval Agency	Number of Outputs	Type	Applications	Voltage - Input (Min) [Min]	Voltage - Isolation	Package / Case	Package / Case	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Voltage - Input (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Voltage - Output 1	Efficiency	Current - Output (Max) [Max]	Mounting Type	Voltage - Output 2	Current - Output (Max)	Features	Voltage - Output 1 [Max]	Voltage - Output 1 [Min]
aimtec AM2GH-1205SZ	CE	1	Isolated Module	ITE (Commercial)	4.5 V	1.6 kV	8-SIP Module	7 Leads	9.2 mm	0.36 "	0.44 "	11.1 mm	21.9 mm	0.86 in	18 V	85 °C	-40 °C	2 W	5 V	74 %	400 mA	Through Hole
aimtec AM2GH-2415DZ	CE	2	Isolated Module	ITE (Commercial)	9 V	1.6 kV	8-SIP Module		9.2 mm	0.36 "	0.44 "	11.1 mm	21.9 mm	0.86 in	36 V	85 °C	-40 °C	2 W		78 %		Through Hole	-15 V	66 mA	Remote On/Off	15 V	-15 V
