7-1415538-7

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE DPDT 8A 24V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

7-1415538-7

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE DPDT 8A 24V

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	7-1415538-7

Approval Agency	cURus, CQC, VDE, CSA
Coil Current	16.7 mA
Coil Insulation	Class F
Coil Resistance	1440 Ohms
Coil Type	Non Latching
Coil Voltage	24 VDC
Contact Form	DPDT (2 Form C)
Contact Material	Silver Nickel (AgNi)
Contact Rating (Current)	8 A
Load - Max Switching	3200 VA
Mounting Type	Through Hole
Must Operate Voltage	16.8 VDC
Must Release Voltage	2.4 VDC
Operate Time	8 ms
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Relay Type	General Purpose
Release Time	6 ms
Seal Rating	Sealed - Flux Protection
Switching Voltage [Max]	400 VAC
Termination Style	PC Pin

RT4240 Series

Part	Coil Current	Operate Time	Contact Form	Release Time	Seal Rating	Coil Resistance	Contact Rating (Current)	Switching Voltage [Max]	Must Operate Voltage	Coil Type	Termination Style	Mounting Type	Must Release Voltage	Approval Agency	Operating Temperature [Max]	Operating Temperature [Min]	Contact Material	Relay Type	Coil Voltage	Load - Max Switching	Coil Insulation
TE Connectivity Potter & Brumfield Relays RT424018	14.2 mA	8 ms	DPDT (2 Form C)	6 ms	Sealed - Flux Protection	810 Ohms	8 A	400 VAC	12.6 VDC	Non Latching	PC Pin	Through Hole	1.8 VDC	CQC CSA cURus VDE	85 °C	-40 °C	Silver Nickel (AgNi)	General Purpose	18 VDC	3200 VA	Class F
TE Connectivity Potter & Brumfield Relays 7-1393243-3	7 mA	8 ms	DPDT (2 Form C)	6 ms	Sealed - Flux Protection	8.57 kOhms	8 A	400 VAC	42 VDC	Non Latching	PC Pin	Through Hole	6 VDC	CQC CSA cURus VDE	85 °C	-40 °C	Silver Nickel (AgNi)	General Purpose	60 VDC	3200 VA	Class F
TE Connectivity Potter & Brumfield Relays RT424006	14.2 mA	8 ms	DPDT (2 Form C)	6 ms	Sealed - Flux Protection	90 Ohms	8 A	400 VAC	4.2 VDC	Non Latching	PC Pin	Through Hole	0.6 VDC	CQC CSA cURus VDE	85 °C	-40 °C	Silver Nickel (AgNi)	General Purpose		3200 VA	Class F
TE Connectivity Potter & Brumfield Relays RT424009	14.2 mA	8 ms	DPDT (2 Form C)	6 ms	Sealed - Flux Protection	200 Ohms	8 A	400 VAC	6.3 VDC	Non Latching	PC Pin	Through Hole	0.9 VDC	CQC CSA cURus VDE	85 °C	-40 °C	Silver Nickel (AgNi)	General Purpose	9 VDC	3200 VA	Class F
TE Connectivity Potter & Brumfield Relays RT424024	14.2 mA	8 ms	DPDT (2 Form C)	6 ms	Sealed - Flux Protection	1440 Ohms	8 A	400 VAC	16.8 VDC	Non Latching	PC Pin	Through Hole	2.4 VDC	CQC CSA cURus VDE	85 °C	-40 °C	Silver Nickel (AgNi)	General Purpose	24 VDC	3200 VA	Class F
TE Connectivity Potter & Brumfield Relays RT424012	14.2 mA	8 ms	DPDT (2 Form C)	6 ms	Sealed - Flux Protection	360 Ohms	8 A	400 VAC	8.4 VDC	Non Latching	PC Pin	Through Hole	1.2 VDC	CQC CSA cURus VDE	85 °C	-40 °C	Silver Nickel (AgNi)	General Purpose	12 VDC	3200 VA	Class F
TE Connectivity Potter & Brumfield Relays 7-1415538-7	16.7 mA	8 ms	DPDT (2 Form C)	6 ms	Sealed - Flux Protection	1440 Ohms	8 A	400 VAC	16.8 VDC	Non Latching	PC Pin	Through Hole	2.4 VDC	CQC CSA cURus VDE	85 °C	-40 °C	Silver Nickel (AgNi)	General Purpose	24 VDC	3200 VA	Class F

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

RT4240 Series

General Purpose Relay DPDT (2 Form C) 24VDC Coil Through Hole
