TPS7A54 Series

Part	Protection Features	Package / Case	Mounting Type	Voltage Dropout (Max)	Number of Regulators	Grade	Qualification	Voltage - Output (Max)	Package Width	Package Name	Package Length	Control Features	Operating Temperature (Min)	Operating Temperature (Max)	Output Configuration	Voltage - Output (Min/Fixed)	PSRR (Maximum)	PSRR (Minimum)	Voltage - Input (Max)	Current - Output	Output Type	Current - Quiescent (Iq)	Current - Supply (Max)
Texas Instruments TPS7A5401QRGRRQ1	Over Temperature Reverse Polarity	20-VFQFN Exposed Pad	Surface Mount	0.51 V	1	Automotive	AEC-Q100	5.1 V	3.5 mm	20-VQFN	3.5 mm	Enable	-40 °C	150 °C	Positive	0.8 V	42 dB	25 dB	6.5 V	4 A	Adjustable
Texas Instruments TPS7A5401RPST	Over Current Over Temperature Under Voltage Lockout (UVLO)	12-VFQFN	Surface Mount	0.565 V	1			5.15 V	2.5 mm	12-VQFN-HR	2.2 mm	Enable Power Good Soft Start	-40 °C	125 °C	Positive	0.8 V	42 dB	39 dB	6.5 V	4 A	Adjustable	4 mA	6 mA
Texas Instruments TPS7A5401RPSR	Over Current Over Temperature Under Voltage Lockout (UVLO)	12-VFQFN	Surface Mount	0.565 V	1			5.15 V	2.5 mm	12-VQFN-HR	2.2 mm	Enable Power Good Soft Start	-40 °C	125 °C	Positive	0.8 V	42 dB	39 dB	6.5 V	4 A	Adjustable	4 mA	6 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
