Connectors, Interconnects
770343-1
ActiveTE Connectivity Raychem Cable Protection
CONN RCPT HSG 2POS 3.68MM
Deep-Dive with AI
Search across all available documentation for this part.
Connectors, Interconnects
770343-1
ActiveTE Connectivity Raychem Cable Protection
CONN RCPT HSG 2POS 3.68MM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 770343-1 |
|---|---|
| Color | Natural |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Male or Female |
| Fastening Type | Locking Ramp |
| Insulation Material | Polyamide (PA), Nylon |
| Mounting Type | Panel Mount, Snap-In |
| Note | Contacts Not Included |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -55 °C |
| Pitch [x] | 3.68 mm |
| Pitch [x] | 0.145 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.61 | |
| 10 | $ 0.51 | |||
| 25 | $ 0.47 | |||
| 50 | $ 0.44 | |||
| 100 | $ 0.42 | |||
| 250 | $ 0.39 | |||
| 500 | $ 0.37 | |||
| 1000 | $ 0.35 | |||
| 2500 | $ 0.32 | |||
Description
General part information
770343 Series
2 Rectangular Connectors - Housings Receptacle Natural 0.145" (3.68mm)
Documents
Technical documentation and resources
No documents available
