RCEF-G-02

Active

Samtec Inc.

CONN MOD PLUG 8P8C UNSHIELDED

Search across all available documentation for this part.

Active

Samtec Inc.

CONN MOD PLUG 8P8C UNSHIELDED

Technical Specifications

Parameters and characteristics for this part

Specification	RCEF-G-02

Cable Type	Round Cable, Not Specified
Color	Clear
Connector Type	Plug
Contact Finish	Gold
Contact Finish Thickness	50 µin
Contact Finish Thickness	1.27 µm
Contact Material	Phosphor Bronze
Features	Latch Lock
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Ingress Protection	IP68 - Dust Tight, Waterproof
Number of Positions/Contacts	8p8c (RJ45, Ethernet)
Ratings	Cat5e
Shielding	Unshielded
Termination	IDC
Wire Gauge	24 AWG

Part	Cable Type	Wire Gauge	Features	Connector Type	Housing Material	Ratings	Color	Contact Finish	Contact Material	Shielding	Ingress Protection	Contact Finish Thickness	Contact Finish Thickness	Termination	Number of Positions/Contacts
Samtec Inc. RCEF-G-01	Round Cable Not Specified	24 AWG	Latch Lock	Plug	Liquid Crystal Polymer (LCP) Glass Filled	Cat5e	Clear	Gold	Phosphor Bronze	Unshielded	IP68 - Dust Tight Waterproof	50 µin	1.27 µm	IDC	8p8c (RJ45 Ethernet)
Samtec Inc. RCEF-G-02	Round Cable Not Specified	24 AWG	Latch Lock	Plug	Liquid Crystal Polymer (LCP) Glass Filled	Cat5e	Clear	Gold	Phosphor Bronze	Unshielded	IP68 - Dust Tight Waterproof	50 µin	1.27 µm	IDC	8p8c (RJ45 Ethernet)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Plug Modular Connector 8p8c (RJ45, Ethernet) Position Unshielded Cat5e IDC

Technical documentation and resources
