KLEA240F-48

Active

Cosel USA, Inc.

AC/DC DIN RAIL SUPPLY 48V 240W

Search across all available documentation for this part.

Active

Cosel USA, Inc.

AC/DC DIN RAIL SUPPLY 48V 240W

Technical Specifications

Parameters and characteristics for this part

Specification	KLEA240F-48

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	ITE (Commercial)
Approval Agency	CE, cURus, cULus
Current - Output (Max) [Max]	5 A
Features	PFC, Adjustable Output, Universal Input
Input Type	AC
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 °C
Power (Watts)	240 W
Size / Dimension [x]	121.2 mm
Size / Dimension [x]	4.77 in
Size / Dimension [y]	1.97 "
Size / Dimension [y]	50 mm
Size / Dimension [z]	115 mm
Size / Dimension [z]	4.53 "
Voltage - Isolation	3000 V
Voltage - Output 1	48 V

Part	Operating Temperature [Min]	Operating Temperature [Max]	Approval Agency	Input Type	Current - Output (Max) [Max]	Applications	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Output 1	Number of Outputs	Efficiency	Voltage - Isolation	Power (Watts)	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Features
Cosel USA, Inc. KLEA240F-24	-20 °C	70 °C	CE cULus cURus	AC	10 A	ITE (Commercial)	121.2 mm	115 mm	4.53 "	1.97 "	50 mm	4.77 in	24 V	1	90 %	3000 V	240 W	85 VAC	264 VAC	Adjustable Output PFC Universal Input
Cosel USA, Inc. KLEA240F-48	-20 °C	70 °C	CE cULus cURus	AC	5 A	ITE (Commercial)	121.2 mm	115 mm	4.53 "	1.97 "	50 mm	4.77 in	48 V	1		3000 V	240 W	85 VAC	264 VAC	Adjustable Output PFC Universal Input

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

AC/DC DIN RAIL SUPPLY 48V 240W
