M57182N-315

Obsolete

Powerex Inc.

DC DC CONVERTER 15V 3W

Search across all available documentation for this part.

Obsolete

Powerex Inc.

DC DC CONVERTER 15V 3W

Technical Specifications

Parameters and characteristics for this part

Specification	M57182N-315

Applications	ITE (Commercial)
Current - Output (Max) [Max]	200 mA
Efficiency	70 %
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max] [custom]	158 °F
Operating Temperature [Min] [custom]	-10 °C
Package / Case	6 Leads
Package / Case	12-SIP Module
Power (Watts)	3 W
Size / Dimension [x]	35.1 mm
Size / Dimension [x]	1.38 "
Size / Dimension [y]	0.34 in
Size / Dimension [y]	8.6 mm
Size / Dimension [z]	0.79 in
Size / Dimension [z]	20.1 mm
Type	Non-Isolated PoL Module
Voltage - Input (Max) [Max]	380 V
Voltage - Input (Min) [Min]	140 V
Voltage - Output 1	15 V

Part	Number of Outputs	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Voltage - Input (Min) [Min]	Package / Case	Package / Case	Efficiency	Power (Watts)	Operating Temperature [Min] [custom]	Operating Temperature [Max] [custom]	Applications	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Output 1	Type	Mounting Type
Powerex Inc. M57182N-315	1	380 V	200 mA	140 V	6 Leads	12-SIP Module	70 %	3 W	-10 °C	158 °F	ITE (Commercial)	0.79 in	0.34 in	20.1 mm	35.1 mm	8.6 mm	1.38 "	15 V	Non-Isolated PoL Module	Through Hole

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Non-Isolated PoL Module DC DC Converter 1 Output 15V 200mA 140V - 380V Input
