C4064A.41.10
ActivePrysmian Group
CABLE 5COND 22AWG GRAY
Deep-Dive with AI
Search across all available documentation for this part.
C4064A.41.10
ActivePrysmian Group
CABLE 5COND 22AWG GRAY
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | C4064A.41.10 |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 7 |
| Conductor Strand [custom] | 30 AWG |
| Jacket (Insulation) Diameter [diameter] | 5.16 mm |
| Jacket (Insulation) Diameter [diameter] | 0.203 in |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Gray |
| Length | 1000 ft |
| Length | 304.8 m, 15.24 m |
| Length [x] | 30.5 m |
| Length [x] | 100 ft, 50 ft |
| Number of Conductors | 5 |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -20 C |
| Usage | Control, Communication |
| Voltage | 300 V |
| Wire Gauge | 22 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 25 | $ 62.20 | |
| 25 | $ 32.90 | |||
| Spool | 1 | $ 468.78 | ||
| 2 | $ 445.74 | |||
| 3 | $ 432.71 | |||
| 5 | $ 416.74 | |||
| 7 | $ 406.49 | |||
| 10 | $ 395.85 | |||
| 25 | $ 369.52 | |||
Description
General part information
C4064 Series
5 Conductor Multi-Conductor Cable Gray 22 AWG 1000.0' (304.8m)
