AST0251204

Active

METZ CONNECT USA Inc.

TERM BLK 12P SIDE ENTRY 5MM PCB

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AST0251204

Active

METZ CONNECT USA Inc.

TERM BLK 12P SIDE ENTRY 5MM PCB

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	5000	$ 3.65

Description

General part information

AST025 Series

12 Position Wire to Board Terminal Block Horizontal with Board 0.197" (5.00mm) Through Hole

Documents

Technical documentation and resources

Datasheet

Specification	AST0251204	AST025 Series

Clamp Material - Plating	Steel	Steel
Color	Gray	Gray
Contact Material - Plating	Copper Alloy - Tin Plated	Copper Alloy - Tin Plated
Current	13 A	13 A
Features	Lever Actuated	Lever Actuated
Housing Material	Polyamide (PA46), Nylon 4/6	Polyamide (PA46), Nylon 4/6
Mating Orientation	Horizontal with Board	Horizontal with Board
Mounting Type	Through Hole	Through Hole
Number of Levels	1	1
Operating Temperature [Max]	105 ░C	105 ░C
Operating Temperature [Min]	-40 °C	-40 °C
Pitch [x]	5 mm	5 mm
Pitch [x]	0.197 in	0.197 in
Positions Per Level	12	2 - 18
Voltage	300 V	300 V
Wire Gauge [Max]	28 AWG	28 AWG
Wire Gauge [Min]	14 AWG	14 AWG
Wire Termination	Screwless - Spring Cage, Tension Clamp	Screwless - Spring Cage, Tension Clamp

Part	Mounting Type	Wire Termination	Number of Levels	Contact Material - Plating	Operating Temperature [Min]	Operating Temperature [Max]	Wire Gauge [Max]	Wire Gauge [Min]	Features	Clamp Material - Plating	Pitch [x]	Pitch [x]	Positions Per Level	Voltage	Color	Housing Material	Current	Mating Orientation
METZ CONNECT USA Inc. AST0250404	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	4	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
METZ CONNECT USA Inc. AST0251004	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	10	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
METZ CONNECT USA Inc. AST0250904	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	9	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
METZ CONNECT USA Inc. AST0251204	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	12	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
METZ CONNECT USA Inc. AST0250804	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	8	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
METZ CONNECT USA Inc. AST0250504	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	5	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
METZ CONNECT USA Inc. AST0250304	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	3	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
METZ CONNECT USA Inc. AST0251604	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	16	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
METZ CONNECT USA Inc. AST0250704	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	7	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
METZ CONNECT USA Inc. AST0251104	Through Hole	Screwless - Spring Cage, Tension Clamp	1	Copper Alloy - Tin Plated	-40 °C	105 ░C	28 AWG	14 AWG	Lever Actuated	Steel	5 mm	0.197 in	11	300 V	Gray	Polyamide (PA46), Nylon 4/6	13 A	Horizontal with Board
