T410-800T - TO-220-3

T410-800T

Active
STMicroelectronics

TRIAC SENS GATE 800V 4A TO220AB

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet+10
T410-800T - TO-220-3

T410-800T

Active
STMicroelectronics

TRIAC SENS GATE 800V 4A TO220AB

Deep-Dive with AI

DocumentsDatasheet+10

Technical Specifications

Parameters and characteristics commom to parts in this series

SpecificationT410-800TT410 Series
--
ConfigurationSingleSingle
Current - Gate Trigger (Igt) (Max) [Max]10 mA10 mA
Current - Hold (Ih) (Max) [Max]15 mA15 - 25 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)31 A, 30 A30 - 42 A
Current - On State (It (RMS)) (Max) [Max]4 A4 A
Mounting TypeThrough HoleThrough Hole, Surface Mount
Operating Temperature [Max]125 ¯C125 - 150 ¯C
Operating Temperature [Min]-40 °C-40 °C
Package / CaseTO-220-3IPAK, TO-251-3 Short Leads, TO-251AA, TO-220-3, SC-63, DPAK (2 Leads + Tab), TO-252-3
Supplier Device PackageTO-220ABTO-251 (IPAK), TO-220AB, TO-220, DPAK
Triac TypeLogic - Sensitive GateLogic - Sensitive Gate
Voltage - Gate Trigger (Vgt) (Max) [Max]1.3 V1 - 1.3 V
Voltage - Off State800 V600 - 800 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyTube 1$ 0.59
10$ 0.51
100$ 0.35
500$ 0.30
1000$ 0.28

T410 Series

4A logic level Triacs

PartVoltage - Off StatePackage / CaseMounting TypeConfigurationCurrent - Non Rep. Surge 50, 60Hz (Itsm)Voltage - Gate Trigger (Vgt) (Max) [Max]Operating Temperature [Min]Operating Temperature [Max]Supplier Device PackageCurrent - Gate Trigger (Igt) (Max) [Max]Current - Hold (Ih) (Max) [Max]Current - On State (It (RMS)) (Max) [Max]Triac Type
STMicroelectronics
T410H-6T
STMicroelectronics
T410-800H
STMicroelectronics
T410-600T
STMicroelectronics
T410-800H
800 V
IPAK, TO-251-3 Short Leads, TO-251AA
Through Hole
Single
30 A, 31 A
1.3 V
-40 °C
125 ¯C
TO-251 (IPAK)
10 mA
15 mA
4 A
Logic - Sensitive Gate
STMicroelectronics
T410-800H
STMicroelectronics
T410-800T
800 V
TO-220-3
Through Hole
Single
30 A, 31 A
1.3 V
-40 °C
125 ¯C
TO-220AB
10 mA
15 mA
4 A
Logic - Sensitive Gate
STMicroelectronics
T410-700T
STMicroelectronics
T410-600B
STMicroelectronics
T410-600B-TR
STMicroelectronics
T410H-6T
600 V
TO-220-3
Through Hole
Single
40 A, 42 A
1 V
-40 °C
150 °C
TO-220
10 mA
25 mA
4 A
Logic - Sensitive Gate

Description

General part information

T410 Series

Based on ST’s Snubberless / logic level technology providing high commutation performances, the T4 series is suitable for use on AC inductive loads. They are recommended for applications using universal motors, electro valves, kitchen aid equipments, power tools, and dishwashers.
