MAX9720AEBE+T
ActiveAnalog Devices Inc./Maxim Integrated
IC AMP CLASS AB STER 50MW 16UCSP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX9720AEBE+T
ActiveAnalog Devices Inc./Maxim Integrated
IC AMP CLASS AB STER 50MW 16UCSP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX9720AEBE+T | MAX9720 Series |
|---|---|---|
| Features | Depop, Short-Circuit and Thermal Protection, Shutdown | Depop, Short-Circuit and Thermal Protection, Shutdown |
| Max Output Power x Channels @ Load | 50 mW, 2 | 2 - 50 mW |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Output Type | Headphones, 2-Channel (Stereo) | Headphones, 2-Channel (Stereo) |
| Package / Case | 16-WFBGA, CSPBGA | 16-WFBGA, CSPBGA, 16-TSSOP |
| Package / Case | - | 0.173 in |
| Package / Case | - | 4.4 mm |
| Supplier Device Package | 16-UCSP (2x2) | 16-UCSP (2x2), 16-TSSOP |
| Type | Class AB | Class AB |
| Voltage - Supply [Max] | 3.6 V | 3.6 V |
| Voltage - Supply [Min] | 1.8 V | 1.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
MAX9720 Series
IC AMP CLASS AB STER 50MW 16UCSP
| Part | Max Output Power x Channels @ Load | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Mounting Type | Type | Features | Output Type | Voltage - Supply [Max] | Voltage - Supply [Min] | Supplier Device Package | Package / Case [x] | Package / Case [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX9720AEBE+T | 2, 50 mW | 85 °C | -40 °C | 16-WFBGA, CSPBGA | Surface Mount | Class AB | Depop, Short-Circuit and Thermal Protection, Shutdown | Headphones, 2-Channel (Stereo) | 3.6 V | 1.8 V | 16-UCSP (2x2) | ||
Analog Devices Inc./Maxim Integrated MAX9720AEUE+ | 2, 50 mW | 85 °C | -40 °C | 16-TSSOP | Surface Mount | Class AB | Depop, Short-Circuit and Thermal Protection, Shutdown | Headphones, 2-Channel (Stereo) | 3.6 V | 1.8 V | 16-TSSOP | 0.173 in | 4.4 mm |
Analog Devices Inc./Maxim Integrated MAX9720BEUE+T | 2, 50 mW | 85 °C | -40 °C | 16-TSSOP | Surface Mount | Class AB | Depop, Short-Circuit and Thermal Protection, Shutdown | Headphones, 2-Channel (Stereo) | 3.6 V | 1.8 V | 16-TSSOP | 0.173 in | 4.4 mm |
Analog Devices Inc./Maxim Integrated MAX9720BEUE+ | 2, 50 mW | 85 °C | -40 °C | 16-TSSOP | Surface Mount | Class AB | Depop, Short-Circuit and Thermal Protection, Shutdown | Headphones, 2-Channel (Stereo) | 3.6 V | 1.8 V | 16-TSSOP | 0.173 in | 4.4 mm |
Analog Devices Inc./Maxim Integrated MAX9720AEUE+T | 2, 50 mW | 85 °C | -40 °C | 16-TSSOP | Surface Mount | Class AB | Depop, Short-Circuit and Thermal Protection, Shutdown | Headphones, 2-Channel (Stereo) | 3.6 V | 1.8 V | 16-TSSOP | 0.173 in | 4.4 mm |
Description
General part information
MAX9720 Series
Amplifier IC Headphones, 2-Channel (Stereo) Class AB 16-UCSP (2x2)
