Specification	9CRA0824P8G001

Air Flow	158.9 CFM
Approval Agency	cURus, TUV
Bearing Type	Ball
Current Rating	2.65 A
Fan Type	Tubeaxial (Dual)
Features	Locked Rotor Protection, PWM Control, Speed Sensor (Tach), Counter-Rotating
Front RPM	12000 RPM
Lifetime	40000 Hrs
Material - Blade	Plastic
Material - Frame	Plastic
Noise	76 dB
Operating Temperature (Max)	158 °F
Operating Temperature (Min)	-4 °F
Power (Watts)	63.6 W
Rear RPM	11300 RPM
Size / Dimension Height	80 mm
Size / Dimension Length	80 mm
Size / Dimension Shape	Square
Static Pressure	4.62 in H2O
Termination	4 Wire Leads per Fan
Termination Leads Count	4
Termination Type	Wire Leads per Fan
Voltage - Rated	24 VAC
Voltage Range (Max)	26.4 VDC
Voltage Range (Min)	21.6 VDC
Weight	0.993 lb
Width	80 mm

9CRA Type Series

DC Fans DC Axial Fan, 80x80x80mm, 24VDC, Counter Rotating, Low Power, Lock Rotor Sensor

Part	Material - Frame	Material - Blade	Voltage - Rated	Termination Leads Count	Termination Type	Termination	Fan Type	Size / Dimension Length	Size / Dimension Shape	Size / Dimension Height	Approval Agency	Features	Bearing Type	Width	Static Pressure	Noise	Power (Watts)	Front RPM	Rear RPM	Air Flow	Operating Temperature (Min)	Operating Temperature (Max)	Weight	Voltage Range (Max)	Voltage Range (Min)	Current Rating	Lifetime
Sanyo Denki America Inc. 9CRA0824G8D001	Plastic	Plastic	24 VAC	3	Wire Leads	3 Wire Leads	Tubeaxial	80 mm	Square	80 mm	cURus TUV	Locked Rotor Sensor	Ball	80 mm
Sanyo Denki America Inc. 9CRA0612P6G001			12 VAC	3	Wire Leads per Fan	3 Wire Leads per Fan	Tubeaxial (Dual)	60 mm	Square	60 mm	cURus TUV	Counter-Rotating Locked Rotor Protection Speed Sensor (Tach)	Ball	56 mm	2.49 in H2O	65 dB	15.6 W	13500 RPM	11400 RPM	58.2 CFM	-4 °F	158 °F	0.441 lb
Sanyo Denki America Inc. 9CRA0812H8001
Sanyo Denki America Inc. 9CRA0812G8001			12 VAC	3	Wire Leads per Fan	3 Wire Leads per Fan	Tubeaxial (Dual)	80 mm	Square	80 mm	cURus TUV	Counter-Rotating Locked Rotor Protection Speed Sensor (Tach)	Ball	80 mm	4.62 in H2O	76 dB	63.6 W	12000 RPM	11300 RPM	158.9 CFM	-4 °F	158 °F	0.993 lb
Sanyo Denki America Inc. 9CRA0312J401			12 VAC	3	Wire Leads per Fan	3 Wire Leads per Fan	Tubeaxial (Dual)	38 mm	Square	38 mm	cURus TUV	Counter-Rotating Locked Rotor Protection Speed Sensor (Tach)	Ball	48 mm	2.25 in H2O	62 dB	13.2 W	16000 RPM	13200 RPM	24.7 CFM	-4 °F	158 °F	0.177 lb
Sanyo Denki America Inc. 9CRA0824P8G001	Plastic	Plastic	24 VAC	4	Wire Leads per Fan	4 Wire Leads per Fan	Tubeaxial (Dual)	80 mm	Square	80 mm	cURus TUV	Counter-Rotating Locked Rotor Protection PWM Control Speed Sensor (Tach)	Ball	80 mm	4.62 in H2O	76 dB	63.6 W	12000 RPM	11300 RPM	158.9 CFM	-4 °F	158 °F	0.993 lb	26.4 VDC	21.6 VDC	2.65 A	40000 Hrs
