EI1805PPOPL
ActiveCARLO GAVAZZI
SENSOR PROX INDUCTIVE 5MM CYLIND
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
EI1805PPOPL
ActiveCARLO GAVAZZI
SENSOR PROX INDUCTIVE 5MM CYLIND
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | EI1805PPOPL |
|---|---|
| Indicator [custom] | LED |
| Ingress Protection | NEMA 4, NEMA 13, NEMA 1, IP67, NEMA 6, NEMA 3 |
| Material - Body | Plastic |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Output Type | PNP-NO, 3-Wire |
| Package / Case | Cylinder, Threaded - M18 |
| Response Frequency | 500 Hz |
| Sensing Distance | 0.197 in |
| Sensing Distance | 5 mm |
| Sensor Type | Inductive |
| Shielding | Unshielded |
| Termination Style | Cable Leads |
| Voltage - Supply [Max] | 40 VDC |
| Voltage - Supply [Min] | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 65.55 | |
| 5 | $ 62.27 | |||
| 10 | $ 60.31 | |||
| 25 | $ 58.34 | |||
Description
General part information
EI1805 Series
SENSOR PROX INDUCTIVE 5MM CYLIND
Documents
Technical documentation and resources
