WP7083SEDK/J3

Active

Kingbright

LED RED DIFFUSED T-1 3/4 T/H

Search across all available documentation for this part.

Active

Kingbright

LED RED DIFFUSED T-1 3/4 T/H

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	20000	$ 0.14

General part information

Red 625nm LED Indication - Discrete 2.2V Radial

Technical documentation and resources

Parameters and characteristics commom to parts in this series

LED RED DIFFUSED T-1 3/4 T/H

Part	Current - Test	Wavelength - Peak [custom]	Wavelength - Dominant	Voltage - Forward (Vf) (Typ)	Supplier Device Package	Lens Style	Configuration	Size / Dimension [diameter]	Color	Lens Color	Package / Case	Height (Max) [Max] [z]	Lens Size	Lens Size	Millicandela Rating	Viewing Angle	Mounting Type	Lens Transparency	Wavelength - Peak
Kingbright WP7083SEDK/J3	20 mA	640 nm	625 nm	2.2 V	T-1 3/4	Round with Domed Top	Standard	5 mm	Red	Orange	Radial	9.85 mm	T-1 3/4	5 mm	1500 mcd	60 °	Through Hole	Diffused
Kingbright WP7083SED/J3	20 mA	640 nm	625 nm	2.2 V	T-1 3/4	Round with Domed Top	Standard	5 mm	Red	Orange	Radial	8.6 mm	T-1 3/4	5 mm	1200 mcd	60 °	Through Hole	Diffused
Kingbright WP7083SYD/J3	20 mA		590 nm	2 V	T-1 3/4	Round with Domed Top	Standard	5 mm	Yellow	Yellow	Radial	8.6 mm	T-1 3/4	5 mm	1000 mcd	60 °	Through Hole	Diffused	590 nm
Kingbright WP7083SYDK/J3	20 mA		590 nm	2 V	T-1 3/4 (5mm)	Round with Domed Top	Standard	5 mm	Yellow	Yellow	Radial	9.85 mm	T-1 3/4	5 mm	900 mcd	60 °	Through Hole	Diffused	590 nm
Kingbright WP7083QBD/G	20 mA		465 nm	3.3 V	T-1 3/4	Round with Domed Top	Standard	5 mm	Blue	Blue	Radial	8.6 mm	T-1 3/4	5 mm	360 mcd	60 °	Through Hole	Diffused	461 nm
Kingbright WP7083ZGD/G	20 mA		525 nm	3.2 V	T-1 3/4	Round with Domed Top	Standard	5 mm	Green	Green	Radial	8.6 mm	T-1 3/4	5 mm	2200 mcd	60 °	Through Hole	Diffused	520 nm
