CFS1/4CT52R511J

Active

KOA Speer Electronics, Inc.

RES CARBON FILM 510 OHM 5% 0.25W(1/4W) -450PPM/°C TO 350PPM/°C CONFORMAL COATED AXL T/R

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CFS1/4CT52R511J

Active

KOA Speer Electronics, Inc.

RES CARBON FILM 510 OHM 5% 0.25W(1/4W) -450PPM/°C TO 350PPM/°C CONFORMAL COATED AXL T/R

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 0.10
		10	$ 0.08
		25	$ 0.06
		50	$ 0.05
		100	$ 0.03
		250	$ 0.03
		500	$ 0.02
		1000	$ 0.01
	Tape & Reel (TR)	5000	$ 0.01
		10000	$ 0.01
		25000	$ 0.01
		50000	$ 0.01
		125000	$ 0.01

Description

General part information

CFS1/4 Series

510 Ohms ±5% 0.25W, 1/4W Through Hole Resistor Axial Carbon Film

Documents

Technical documentation and resources

Specification	CFS1/4CT52R511J	CFS1/4 Series

Composition	Carbon Film	Carbon Film
Number of Terminations	2	2
Operating Temperature [Max]	155 °C	155 °C
Operating Temperature [Min]	-55 °C	-55 °C
Package / Case	Axial	Axial
Power (Watts)	0.25 W	0.25 W
Power (Watts)	250 mW	250 mW
Resistance	510 Ohms	2.4 - 10000 kOhms
Size / Dimension [diameter]	0.067 in	0.067 in
Size / Dimension [diameter]	1.7 mm	1.7 mm
Size / Dimension [x]	3.2 mm	3.2 mm
Size / Dimension [x]	0.126 in	0.126 in
Supplier Device Package	Axial	Axial
Temperature Coefficient [Max]	350 ppm/°C	-700 - 350
Temperature Coefficient [Min]	-450 ppm/°C	-1300 - 0 ppm/°C
Tolerance	5 %	2 - 5 %

Part	Power (Watts)	Power (Watts)	Operating Temperature [Max]	Operating Temperature [Min]	Number of Terminations	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [diameter]	Size / Dimension [diameter]	Supplier Device Package	Package / Case	Resistance	Tolerance	Composition	Temperature Coefficient [Max]	Temperature Coefficient [Min]
KOA Speer Electronics, Inc. CFS1/4CT52R684J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	680 kOhms	5 %	Carbon Film	0	-1300 ppm/°C
KOA Speer Electronics, Inc. CFS1/4C101J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	100 Ohms	5 %	Carbon Film	350 ppm/°C	-450 ppm/°C
KOA Speer Electronics, Inc. CFS1/4CT52R511J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	510 Ohms	5 %	Carbon Film	350 ppm/°C	-450 ppm/°C
KOA Speer Electronics, Inc. CFS1/4CT52R222J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	2200 Ohms	5 %	Carbon Film	350 ppm/°C	-450 ppm/°C
KOA Speer Electronics, Inc. CFS1/4CT52R184J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	180 kOhms	5 %	Carbon Film	0	-1000 ppm/°C
KOA Speer Electronics, Inc. CFS1/4CT52R513J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	51 kOhms	5 %	Carbon Film	-700 ppm/°C	0 ppm/°C
KOA Speer Electronics, Inc. CFS1/4CT52R102J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	1000 Ohms	5 %	Carbon Film	350 ppm/°C	-450 ppm/°C
KOA Speer Electronics, Inc. CFS1/4CT52R152J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	1500 Ohms	5 %	Carbon Film	350 ppm/°C	-450 ppm/°C
KOA Speer Electronics, Inc. CFS1/4CT52R472J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	4.7 kOhms	5 %	Carbon Film	350 ppm/°C	-450 ppm/°C
KOA Speer Electronics, Inc. CFS1/4CT52R471J	0.25 W	250 mW	155 °C	-55 °C	2	3.2 mm	0.126 in	0.067 in	1.7 mm	Axial	Axial	470 Ohms	5 %	Carbon Film	350 ppm/°C	-450 ppm/°C
