42CF35AF

Active

Siemens

CONTACTOR, 42DP,40A,3P,OPEN,120V

Search across all available documentation for this part.

Active

Siemens

CONTACTOR, 42DP,40A,3P,OPEN,120V

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Operating Temperature	Contact Rating (Current)	Coil Voltage	Contact Form	Features	Termination Style	Switching Voltage	Coil Voltage [Min]	Coil Voltage [Max]
Siemens 42CF15AL	Chassis Mount	70 °C	40 A	277 VAC	DPST-NO (2 Form A)	Auxiliary Contacts	Screw Terminal	600 VAC
Siemens 42CF35AG	Chassis Mount	70 °C	40 A		3PST-NO (3 Form A)	Auxiliary Contacts	Screw Terminal	600 VAC	208 VAC	240 VAC
Siemens 42CF15AJ	Chassis Mount	70 °C	40 A	24 VAC	DPST-NO (2 Form A)	Auxiliary Contacts	Screw Terminal	600 VAC
Siemens 42CF15AF	Chassis Mount	70 °C	40 A		DPST-NO (2 Form A)	Auxiliary Contacts	Screw Terminal	600 VAC	110 VAC/DC	120 VAC
Siemens 42CF35AH	Chassis Mount	70 °C	40 A		3PST-NO (3 Form A)	Auxiliary Contacts	Screw Terminal	600 VAC	440 VAC/DC	480 VAC/DC
Siemens 42CF35AL	Chassis Mount	70 °C	40 A	277 VAC	3PST-NO (3 Form A)	Auxiliary Contacts	Screw Terminal	600 VAC
Siemens 42CF35AF	Chassis Mount	70 °C	40 A		3PST-NO (3 Form A)	Auxiliary Contacts	Screw Terminal	600 VAC	110 VAC/DC	120 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

CONTACTOR, 42DP,40A,3P,OPEN,120V
