Specification	C10PC,BK

Area (L x W)	7.48 in²
Color	Black
Container Type	Box
Design	Split Sides, Hand Held
Features	Pocket Clip
Height	0.8 in
Material	ABS, Plastic
Material Flammability Rating	UL94 HB
Ratings	IP40
Size / Dimension Length	3.25 in
Size / Dimension Width	2.3 in
Thickness	0.09 in
Weight	0.043 lb

C Series

Part	Weight	Container Type	Material Flammability Rating	Material	Area (L x W)	Thickness	Design	Ratings	Size / Dimension Length	Size / Dimension Width	Height	Color	Features
Serpac C28,BK	0.084 lb	Box	UL94 HB	ABS Plastic	9.25 in²	0.1 in	Hand Held Split Sides	IP40	5 in	1.85 in	25.4 mm	Black
Serpac C10PC,BK	0.043 lb	Box	UL94 HB	ABS Plastic	7.48 in²	0.09 in	Hand Held Split Sides	IP40	3.25 in	2.3 in	0.8 in	Black	Pocket Clip
Serpac C8PC,BK	0.042 lb	Box	UL94 HB	ABS Plastic	4.44 in²	0.06 in	Hand Held Split Sides	IP40	2.4 in	1.85 in	0.93 in	Black	Pocket Clip
