SKY13317-373LF-EVB

Active

Skyworks Solutions Inc.

BOARD EVAL SP3T SW SKY13317-373

Search across all available documentation for this part.

Active

Skyworks Solutions Inc.

BOARD EVAL SP3T SW SKY13317-373

Technical Specifications

Parameters and characteristics for this part

Specification	SKY13317-373LF-EVB

For Use With/Related Products	SKY13317-373LF
Frequency [Max]	6 GHz
Frequency [Min]	100 MHz
Supplied Contents	Board(s)
Type	Switch

Part	Supplier Device Package	Isolation	Circuit	RF Type	Operating Temperature [Max]	Operating Temperature [Min]	Test Frequency	Impedance	Insertion Loss	IIP3	P1dB	Topology	Frequency Range [Min]	Frequency Range [Max]	Mounting Type	Package / Case	For Use With/Related Products	Supplied Contents	Type	Frequency [Max]	Frequency [Min]
Skyworks Solutions Inc. SKY13317-373LF	8-MLP (1.5x1.5)	25 dB	SP3T	802.11a/b/g/WiFi WLAN	100 °C	-40 °C	5.9 GHz	50 Ohms	0.8 dB	50 dBm	26 dBm	Reflective	20 MHz	6 GHz	Surface Mount	8-XFDFN Exposed Pad
Skyworks Solutions Inc. SKY13317-373LF-EVB																	SKY13317-373LF	Board(s)	Switch	6 GHz	100 MHz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 106.24

General part information

- SKY13317-373LF Switch 100MHz ~ 6GHz Evaluation Board
