Specification	5532448-9

Color	Black
Connector Style	High Density (HDC, HDI, HPC)
Connector Type	Header, Male Pins
Contact Finish	Gold
Contact Finish Thickness	30 µin
Features	Mating Guide
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	240
Number of Positions Loaded	All
Number of Rows	4
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-65 °C
Pitch	0.1 in
Termination	Press-Fit

5532448 Series

Part	Operating Temperature (Max)	Operating Temperature (Min)	Material Flammability Rating	Number of Positions Loaded	Number of Positions	Mounting Type	Color	Contact Finish Thickness	Connector Style	Pitch	Features	Termination	Contact Finish	Number of Rows	Connector Type
TE Connectivity AMP Connectors 5532448-9	125 °C	-65 °C	UL94 V-0	All	240	Through Hole	Black	30 µin	High Density (HDC HDI HPC)	0.1 in	Mating Guide	Press-Fit	Gold	4	Header Male Pins
TE Connectivity AMP Connectors 5532448-4	125 °C	-65 °C	UL94 V-0	All	140	Through Hole	Black	30 µin	High Density (HDC HDI HPC)	0.1 in	Mating Guide	Press-Fit	Gold	4	Header Male Pins
TE Connectivity AMP Connectors 5532448-6	125 °C	-65 °C	UL94 V-0	All	180	Through Hole	Black	30 µin	High Density (HDC HDI HPC)	0.1 in	Mating Guide	Press-Fit	Gold	4	Header Male Pins
