IXDD514D1

Obsolete

IXYS

IC GATE DRVR LOW-SIDE 6DFN

Search across all available documentation for this part.

Obsolete

IXYS

IC GATE DRVR LOW-SIDE 6DFN

Technical Specifications

Parameters and characteristics for this part

Specification	IXDD514D1

Channel Type	Single
Current - Peak Output (Source, Sink) [custom]	14 A
Current - Peak Output (Source, Sink) [custom]	14 A
Driven Configuration	Low-Side
Input Type	Non-Inverting
Logic Voltage - VIL, VIH	2.5 V, 1 V
Mounting Type	Surface Mount
Number of Drivers	1
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-55 °C
Package / Case	6-VDFN Exposed Pad
Rise / Fall Time (Typ) [custom]	25 ns
Rise / Fall Time (Typ) [custom]	22 ns
Supplier Device Package	6-DFN (4x5)
Voltage - Supply [Max]	30 VDC
Voltage - Supply [Min]	4.5 V

Part	Package / Case	Package / Case [y]	Package / Case [x]	Current - Peak Output (Source, Sink) [custom]	Current - Peak Output (Source, Sink) [custom]	Supplier Device Package	Input Type	Mounting Type	Logic Voltage - VIL, VIH	Operating Temperature [Min]	Operating Temperature [Max]	Channel Type	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Number of Drivers	Driven Configuration	Voltage - Supply [Min]	Voltage - Supply [Max]
IXYS IXDD514SIA	8-SOIC	3.9 mm	0.154 in	14 A	14 A	8-SOIC	Non-Inverting	Surface Mount	1 V 2.5 V	-55 °C	150 °C	Single	25 ns	22 ns	1	Low-Side	4.5 V	30 VDC
IXYS IXDD514D1	6-VDFN Exposed Pad			14 A	14 A	6-DFN (4x5)	Non-Inverting	Surface Mount	1 V 2.5 V	-55 °C	150 °C	Single	25 ns	22 ns	1	Low-Side	4.5 V	30 VDC
IXYS IXDD514SIAT/R	8-SOIC	3.9 mm	0.154 in	14 A	14 A	8-SOIC	Non-Inverting	Surface Mount	1 V 2.5 V	-55 °C	150 °C	Single	25 ns	22 ns	1	Low-Side	4.5 V	30 VDC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Low-Side Gate Driver IC Non-Inverting 6-DFN (4x5)
