7813J-1-023E
ActiveBourns Inc.
SWITCH ROTARY DIP SPDT 0.1A 16V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
7813J-1-023E
ActiveBourns Inc.
SWITCH ROTARY DIP SPDT 0.1A 16V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 7813J-1-023E |
|---|---|
| Actuator Level | Flush, Recessed |
| Actuator Type | Rotary for Tool |
| Circuit | SPDT |
| Current Rating (Amps) | 100 mA |
| Height Above Board | 0.087 in |
| Height Above Board | 2.2 mm |
| Length [x] | 0.126 in |
| Length [x] | 3.2 mm |
| Mechanical Life | 2000 Cycles |
| Mounting Type | Surface Mount |
| Number of Positions | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Termination Style | J Lead |
| Voltage Rating | 16 VAC/DC |
| Washable | False |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.67 | |
| 10 | $ 1.62 | |||
| 25 | $ 1.47 | |||
| 100 | $ 1.28 | |||
| 250 | $ 1.16 | |||
| 500 | $ 1.08 | |||
| Digi-Reel® | 1 | $ 1.67 | ||
| 10 | $ 1.62 | |||
| 25 | $ 1.47 | |||
| 100 | $ 1.28 | |||
| 250 | $ 1.16 | |||
| 500 | $ 1.08 | |||
| Tape & Reel (TR) | 1000 | $ 1.00 | ||
| 3000 | $ 0.91 | |||
| 5000 | $ 0.84 | |||
| 10000 | $ 0.82 | |||
Description
General part information
7813J Series
Dip Switch SPDT 2 Position Surface Mount Rotary for Tool Actuator 100mA 16VAC/DC
