DS1318E+
ActiveAnalog Devices Inc./Maxim Integrated
IC RTC ELAPSED CNT PAR 24TSSOP
Deep-Dive with AI
Search across all available documentation for this part.
DS1318E+
ActiveAnalog Devices Inc./Maxim Integrated
IC RTC ELAPSED CNT PAR 24TSSOP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DS1318E+ | DS1318 Series |
|---|---|---|
| Current - Timekeeping (Max) | 150 µA | 150 µA |
| Date Format | Binary | Binary |
| Features | Alarm, Square Wave Output | Alarm, Square Wave Output |
| Interface | Parallel | Parallel |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 24-TSSOP | 24-TSSOP |
| Package / Case | 0.173 in, 4.4 mm | 0.173 - 4.4 in |
| Supplier Device Package | 24-TSSOP | 24-TSSOP |
| Time Format | Binary | Binary |
| Type | Elapsed Time Counter | Elapsed Time Counter |
| Voltage - Supply [Max] | 3.6 V | 3.6 V |
| Voltage - Supply [Min] | 3 V | 3 V |
| Voltage - Supply, Battery [Max] | 3.7 V | 3.7 V |
| Voltage - Supply, Battery [Min] | 1.6 V | 1.6 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 7.52 | |
| 10 | $ 5.14 | |||
| 25 | $ 4.52 | |||
| 100 | $ 3.83 | |||
| 250 | $ 3.49 | |||
| 500 | $ 3.29 | |||
| 1000 | $ 3.12 | |||
| 2500 | $ 2.96 | |||
DS1318 Series
IC RTC ELAPSED CNT PAR 24TSSOP
| Part | Interface | Mounting Type | Supplier Device Package | Package / Case | Package / Case | Date Format | Operating Temperature [Max] | Operating Temperature [Min] | Features | Current - Timekeeping (Max) | Type | Voltage - Supply [Max] | Voltage - Supply [Min] | Time Format | Voltage - Supply, Battery [Max] | Voltage - Supply, Battery [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated DS1318E+ | Parallel | Surface Mount | 24-TSSOP | 24-TSSOP | 0.173 in, 4.4 mm | Binary | 85 °C | -40 °C | Alarm, Square Wave Output | 150 µA | Elapsed Time Counter | 3.6 V | 3 V | Binary | 3.7 V | 1.6 V |
Analog Devices Inc./Maxim Integrated DS1318E+T&R | Parallel | Surface Mount | 24-TSSOP | 24-TSSOP | 0.173 in, 4.4 mm | Binary | 85 °C | -40 °C | Alarm, Square Wave Output | 150 µA | Elapsed Time Counter | 3.6 V | 3 V | Binary | 3.7 V | 1.6 V |
Analog Devices Inc./Maxim Integrated DS1318 | Parallel | Surface Mount | 24-TSSOP | 24-TSSOP | 0.173 in, 4.4 mm | Binary | 85 °C | -40 °C | Alarm, Square Wave Output | 150 µA | Elapsed Time Counter | 3.6 V | 3 V | Binary | 3.7 V | 1.6 V |
Description
General part information
DS1318 Series
Real Time Clock (RTC) IC Elapsed Time Counter Parallel 24-TSSOP (0.173", 4.40mm Width)
