9GV0412P3J03

Obsolete

Sanyo Denki America Inc.

FAN AXIAL 40X28MM 12VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsRotor Balancing Handling Instructions for Fan Motors

9GV0412P3J03

Obsolete

Sanyo Denki America Inc.

FAN AXIAL 40X28MM 12VDC WIRE

Deep-Dive with AI

DocumentsRotor Balancing Handling Instructions for Fan Motors

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	9GV0412P3J03

Air Flow	24 CFM
Air Flow	0.672 mł/min
Approval Agency	CSA, TUV, UL
Bearing Type	Ball
Current Rating (Amps)	600 mA
Fan Type	Tubeaxial
Features	Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Lifetime @ Temp.	40000 Hrs
Material - Blade	Plastic
Material - Frame	Plastic
Noise	55 dB
Operating Temperature [Max]	60 °C
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-20 °C
Operating Temperature [Min]	-20 C
Power (Watts)	7.2 W
RPM	14700 RPM
Size / Dimension	Square
Size / Dimension [x]	40 mm
Size / Dimension [z]	40 mm
Static Pressure	330 Pa
Static Pressure	1.325 in H2O
Termination	4 Wire Leads
Voltage - Rated	12 VDC
Voltage Range [Max]	13.2 VDC
Voltage Range [Min]	7 V
Weight	0.111 lb
Weight	50.35 g
Width [y]	28 mm

9GV0412 Series

Part	Voltage Range [Max]	Voltage Range [Min]	Static Pressure	Static Pressure	Material - Frame	Fan Type	Noise	Material - Blade	Width [y]	RPM	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [z]	Size / Dimension	Size / Dimension [x]	Termination	Voltage - Rated	Power (Watts)	Features	Lifetime @ Temp.	Bearing Type	Approval Agency	Air Flow	Air Flow	Weight	Weight	Current Rating (Amps)	Operating Temperature [Max]
Sanyo Denki America Inc. 9GV0412J301	13.2 VDC	7 V	330 Pa	1.325 in H2O	Plastic	Tubeaxial	55 dB	Plastic	28 mm	14700 RPM	60 °C	-20 °C	-20 C	60 °C	40 mm	Square	40 mm	3 Wire Leads	12 VDC	7.2 W	Speed Sensor (Tach)	40000 Hrs	Ball	CSA TUV UL	24 CFM	0.672 mł/min	0.111 lb	50.35 g	600 mA
Sanyo Denki America Inc. 9GV0412H3011	13.2 VDC	7 V	207 Pa	0.831 in H2O	Plastic	Tubeaxial	49 dB	Plastic	28 mm	11600 RPM	60 °C	-20 °C	-20 C	60 °C	40 mm	Square	40 mm	3 Wire Leads	12 VDC	3.72 W	Locked Rotor Protection Speed Sensor (Tach)	40000 Hrs	Ball	CSA TUV UL	18.7 CFM	0.524 mł/min	0.111 lb	50.35 g	0.31 A
Sanyo Denki America Inc. 9GV0412G302	13.2 VDC	7 V	260 Pa	1.044 in H2O	Plastic	Tubeaxial	52 dB	Plastic	28 mm	13000 RPM		-10 °C	-10 °C	60 °C	40 mm	Square	40 mm	2 Wire Leads	12 VDC	5.64 W		40000 Hrs	Ball	CSA TUV UL	21.1 CFM	0.591 m³/min	0.111 lb	50.35 g	0.47 A	60 °C
Sanyo Denki America Inc. 9GV0412K3D01	12.6 VDC	10.8 VDC	415.5 Pa	1.668 in H2O	Plastic	Tubeaxial	58 dB(A)	Plastic	28 mm	16500 RPM	60 °C	-20 °C	-20 C	60 °C	40 mm	Square	40 mm	3 Wire Leads	12 VDC	10.08 W	Locked Rotor Sensor	40000 Hrs	Ball	CSA TUV UL	26.8 CFM	0.75 mł/min	0.111 lb	50.35 g	0.84 A
Sanyo Denki America Inc. 9GV0412C3D01	13.2 VDC	7 V	100.1 Pa	0.402 in H2O	Plastic	Tubeaxial	41 dB	Plastic	28 mm	8300 RPM	70 °C	-20 °C	-20 C	70 °C	40 mm	Square	40 mm	3 Wire Leads	12 VDC	1.8 W	Locked Rotor Sensor	40000 Hrs	Ball	CSA TUV UL	13.1 CFM	0.367 mł/min	0.111 lb	50.35 g	150 mA
Sanyo Denki America Inc. 9GV0412P3J031	13.2 VDC	7 V	330 Pa	1.325 in H2O	Plastic	Tubeaxial	55 dB	Plastic	28 mm	14700 RPM	60 °C	-20 °C	-20 C	60 °C	40 mm	Square	40 mm	4 Wire Leads	12 VDC	7.2 W	Locked Rotor Protection PWM Control Speed Sensor (Tach)	40000 Hrs	Ball	CSA TUV UL	24 CFM	0.672 mł/min	0.111 lb	50.35 g	600 mA
Sanyo Denki America Inc. 9GV0412P3J03	13.2 VDC	7 V	330 Pa	1.325 in H2O	Plastic	Tubeaxial	55 dB	Plastic	28 mm	14700 RPM	60 °C	-20 °C	-20 C	60 °C	40 mm	Square	40 mm	4 Wire Leads	12 VDC	7.2 W	Locked Rotor Protection PWM Control Speed Sensor (Tach)	40000 Hrs	Ball	CSA TUV UL	24 CFM	0.672 mł/min	0.111 lb	50.35 g	600 mA
Sanyo Denki America Inc. 9GV0412K302	12.6 VDC	10.8 VDC	415.5 Pa	1.668 in H2O	Plastic	Tubeaxial	58 dB(A)	Plastic	28 mm	16500 RPM	60 °C	-20 °C	-20 C	60 °C	40 mm	Square	40 mm	2 Wire Leads	12 VDC	10.08 W		40000 Hrs	Ball	CSA TUV UL	26.8 CFM	0.75 mł/min	0.111 lb	50.35 g	0.84 A
Sanyo Denki America Inc. 9GV0412C301	13.2 VDC	7 V	100.1 Pa	0.402 in H2O	Plastic	Tubeaxial	41 dB	Plastic	28 mm	8300 RPM	70 °C	-20 °C	-20 C	70 °C	40 mm	Square	40 mm	3 Wire Leads	12 VDC	1.8 W	Locked Rotor Protection Speed Sensor (Tach)	40000 Hrs	Ball	CSA TUV UL	13.1 CFM	0.367 mł/min	0.111 lb	50.35 g	150 mA
Sanyo Denki America Inc. 9GV0412G3D01	13.2 VDC	7 V	260 Pa	1.044 in H2O	Plastic	Tubeaxial	52 dB	Plastic	28 mm	13000 RPM	60 °C	-20 °C	-20 C	60 °C	40 mm	Square	40 mm	3 Wire Leads	12 VDC	5.64 W	Locked Rotor Sensor	40000 Hrs	Ball	CSA TUV UL	21.1 CFM	0.591 m³/min	0.111 lb	50.35 g	0.47 A

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

9GV0412 Series

Fan Tubeaxial 12VDC Square - 40mm L x 40mm H Ball 24.0 CFM (0.672m³/min) 4 Wire Leads
