4013C-20

Active

L3 Narda-MITEQ

RF DIR COUPLER 2GHZ-4GHZ MODULE

Search across all available documentation for this part.

Active

L3 Narda-MITEQ

RF DIR COUPLER 2GHZ-4GHZ MODULE

Technical Specifications

Parameters and characteristics commom to parts in this series

RF DIR COUPLER 2GHZ-4GHZ MODULE

Part	Package / Case	Power - Max [Max]	Insertion Loss	Coupler Type	Supplier Device Package	Applications	Frequency [Min]	Frequency [Max]	Coupling Factor
L3 Narda-MITEQ 4013C-20	Module	50 W	0.25 dB	Standard	Module	General Purpose	2 GHz	4 GHz	20 dB
L3 Narda-MITEQ 4013C-30	Module, SMA Connectors	50 W	0.2 dB	Standard	Module	General Purpose	2 GHz	4 GHz	30 dB
L3 Narda-MITEQ 4013C-6	Module	50 W	1.8 dB	Standard	Module	General Purpose	2 GHz	4 GHz	6 dB

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

RF Directional Coupler General Purpose 2GHz ~ 4GHz 20 ± 1.25dB 50W Module
