A89506KESSR-J
ActiveAllegro MicroSystems
IC GATE DRVR FULL-BRIDGE 20QFN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
A89506KESSR-J
ActiveAllegro MicroSystems
IC GATE DRVR FULL-BRIDGE 20QFN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | A89506KESSR-J |
|---|---|
| Channel Type | Synchronous |
| Driven Configuration | Full-Bridge |
| Gate Type | MOSFET (N-Channel) |
| Input Type | Non-Inverting |
| Logic Voltage - VIL, VIH | 0.8 V, 2 V |
| Mounting Type | Surface Mount |
| Number of Drivers | 4 |
| Operating Temperature [Max] | 135 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 20-WFQFN Exposed Pad |
| Supplier Device Package | 20-QFN-EP (4x4) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.06 | |
| 10 | $ 1.52 | |||
| 25 | $ 1.39 | |||
| 100 | $ 1.24 | |||
| 250 | $ 1.17 | |||
| 500 | $ 1.13 | |||
| 1000 | $ 1.09 | |||
| 2500 | $ 1.05 | |||
| Digi-Reel® | 1 | $ 2.06 | ||
| 10 | $ 1.52 | |||
| 25 | $ 1.39 | |||
| 100 | $ 1.24 | |||
| 250 | $ 1.17 | |||
| 500 | $ 1.13 | |||
| 1000 | $ 1.09 | |||
| 2500 | $ 1.05 | |||
| Tape & Reel (TR) | 6000 | $ 0.95 | ||
Description
General part information
A89506 Series
Full-Bridge Gate Driver IC Non-Inverting 20-QFN-EP (4x4)
