TBR-MB-6-1P-SC

Active

c3controls

RELAY GEN PURPOSE SPDT 6A 12V

Search across all available documentation for this part.

Active

c3controls

RELAY GEN PURPOSE SPDT 6A 12V

Technical Specifications

Parameters and characteristics commom to parts in this series

RELAY GEN PURPOSE SPDT 6A 24V

Part	Operate Time	Operating Temperature [Min]	Operating Temperature [Max]	Must Release Voltage	Contact Rating (Current)	Contact Form	Termination Style	Must Operate Voltage	Coil Voltage	Contact Material	Coil Type	Mounting Type	Switching Voltage [Max]	Release Time	Relay Type	Coil Voltage [Min]	Coil Voltage [Max]
c3controls TBR-MC-6-1P-SC	8 ms	-40 °C	55 °C	2.4 VAC/DC	6 A	SPDT (1 Form C)	Screw Terminal	21.6 VAC	24 VAC	Silver Nickel (AgNi)	Non Latching	DIN Rail	30 VDC, 250 VAC	4 ms	General Purpose
c3controls TBR-MF-6-1P-SC	8 ms	-40 °C	55 °C		6 A	SPDT (1 Form C)	Screw Terminal			Silver Nickel (AgNi)	Non Latching	DIN Rail	30 VDC, 250 VAC	4 ms	General Purpose	220 VAC	240 VAC
c3controls TBR-MD-6-1P-SC	8 ms	-40 °C	55 °C		6 A	SPDT (1 Form C)	Screw Terminal			Silver Nickel (AgNi)	Non Latching	DIN Rail	30 VDC, 250 VAC	4 ms	General Purpose	110 VAC/DC	125 VAC
c3controls TBR-MB-6-1P-SC	8 ms	-40 °C	55 °C	1.2 VAC	6 A	SPDT (1 Form C)	Screw Terminal	10.8 VAC/DC	12 VAC/DC	Silver Nickel (AgNi)	Non Latching	DIN Rail	30 VDC, 250 VAC	4 ms	General Purpose

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 9.77

General part information

General Purpose Relay SPDT (1 Form C) 12VAC/DC Coil DIN Rail
