NH3030 2

Active

APM HEXSEAL

PUSHBUTTON FULL BOOT GRAY

Search across all available documentation for this part.

Active

APM HEXSEAL

PUSHBUTTON FULL BOOT GRAY

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	250	$ 2.46

General part information

PUSHBUTTON FULL BOOT GRAY

Technical documentation and resources

Specification	NH3030 2	NH3030 Series

Actuator Diameter [diameter]	0.422 in	0.422 in
Actuator Diameter [diameter]	10.72 mm	10.72 mm
Color	Gray	Gray
Features	-	Shielded
For Use With/Related Products	Multiple Series	Multiple Series
Ingress Protection	IP66/IP68	IP66/IP68
Material	Silicone Rubber	Silicone Rubber
Mounting Feature	Front of Panel	Front of Panel
Operating Temperature [Max]	204 °C	204 °C
Operating Temperature [Min]	-70 °C	-70 °C
Size / Dimension [z]	0.547 in	0.547 in
Size / Dimension [z]	13.89 mm	13.89 mm
Thread Size	1/2-32 NS-2B	1/2-32 NS-2B
Type	Pushbutton, Full Boot	Pushbutton, Full Boot

Part	Ingress Protection	Mounting Feature	Type	Thread Size	Operating Temperature [Max]	Operating Temperature [Min]	Actuator Diameter [diameter]	Actuator Diameter [diameter]	Size / Dimension [z]	Size / Dimension [z]	Features	For Use With/Related Products	Color	Material
APM HEXSEAL NH3030 RFI 2	IP66/IP68	Front of Panel	Pushbutton, Full Boot	1/2-32 NS-2B	204 °C	-70 °C	0.422 in	10.72 mm	0.547 in	13.89 mm	Shielded	Multiple Series	Gray	Silicone Rubber
APM HEXSEAL NH3030 2	IP66/IP68	Front of Panel	Pushbutton, Full Boot	1/2-32 NS-2B	204 °C	-70 °C	0.422 in	10.72 mm	0.547 in	13.89 mm		Multiple Series	Gray	Silicone Rubber
