CFRM103-G

Active

Comchip Technology

DIODE GP 200V 1A MINI SMA/SOD123

Search across all available documentation for this part.

Active

Comchip Technology

DIODE GP 200V 1A MINI SMA/SOD123

Technical Specifications

Parameters and characteristics for this part

Specification	CFRM103-G

Current - Average Rectified (Io)	1 A
Current - Reverse Leakage @ Vr	1 µA
Mounting Type	Surface Mount
Operating Temperature - Junction [Max]	150 °C
Operating Temperature - Junction [Min]	-55 °C
Package / Case	SOD-123T
Reverse Recovery Time (trr)	150 ns
Speed	200 mA, 500 ns
Supplier Device Package	Mini SMA/SOD-123
Technology	Standard
Voltage - DC Reverse (Vr) (Max) [Max]	200 V
Voltage - Forward (Vf) (Max) @ If	1.3 V

DIODE GP 200V 1A MINI SMA/SOD123

Part	Technology	Supplier Device Package	Current - Reverse Leakage @ Vr	Current - Average Rectified (Io)	Speed	Voltage - Forward (Vf) (Max) @ If	Package / Case	Mounting Type	Voltage - DC Reverse (Vr) (Max) [Max]	Reverse Recovery Time (trr)	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]
Comchip Technology CFRM103-G	Standard	Mini SMA/SOD-123	1 µA	1 A	200 mA, 500 ns	1.3 V	SOD-123T	Surface Mount	200 V	150 ns	150 °C	-55 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Diode 200 V 1A Surface Mount Mini SMA/SOD-123

Technical documentation and resources

No documents available
