CD07AR-BK

Active

Sealcon

CABLE GLAND 2.03-5.08MM PG7

Search across all available documentation for this part.

Active

Sealcon

CABLE GLAND 2.03-5.08MM PG7

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	8	$ 1.32

General part information

Cable Gland Polyamide (PA66), Nylon 6/6 PG7 Black

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	CD07AR-BK	CD07AR Series

Color	Black	Gray, Black
Ingress Protection	IP69K, IP68, NEMA 6	IP69K, IP68, NEMA 6
Material	Polyamide (PA66), Nylon 6/6	Polyamide (PA66), Nylon 6/6
Operating Temperature [Max]	100 °C	100 °C
Operating Temperature [Min]	-40 °C	-40 °C
Outside Cable Diameter (Max) [Max]	0.2 in	0.2 in
Outside Cable Diameter (Max) [Max]	5.08 mm	5.08 mm
Outside Cable Diameter (Min) [Min] [diameter]	0.08 in	0.08 in
Outside Cable Diameter (Min) [Min] [diameter]	2.03 mm	2.03 mm
Panel Hole Size [diameter]	12.4 mm	12.4 mm
Panel Hole Size [diameter]	0.49 in	0.49 in
Thread Length	7.87 mm	7.87 mm
Thread Length	0.31 in	0.31 in
Thread Size	PG7	PG7
Type	Cable Gland	Cable Gland

CABLE GLAND 2.03-5.08MM PG7

Part	Outside Cable Diameter (Min) [Min] [diameter]	Outside Cable Diameter (Min) [Min] [diameter]	Thread Length	Thread Length	Operating Temperature [Max]	Operating Temperature [Min]	Ingress Protection	Panel Hole Size [diameter]	Panel Hole Size [diameter]	Outside Cable Diameter (Max) [Max]	Outside Cable Diameter (Max) [Max]	Material	Type	Color	Thread Size
Sealcon CD07AR-GY	0.08 in	2.03 mm	7.87 mm	0.31 in	100 °C	-40 °C	IP68, IP69K, NEMA 6	12.4 mm	0.49 in	0.2 in	5.08 mm	Polyamide (PA66), Nylon 6/6	Cable Gland	Gray	PG7
Sealcon CD07AR-BK	0.08 in	2.03 mm	7.87 mm	0.31 in	100 °C	-40 °C	IP68, IP69K, NEMA 6	12.4 mm	0.49 in	0.2 in	5.08 mm	Polyamide (PA66), Nylon 6/6	Cable Gland	Black	PG7
