RFD-1687-4

Active

RF Industries

HEADER 6GHZ -55℃~+85℃ 50Ω COAXIAL CONNECTORS (RF) ROHS

Search across all available documentation for this part.

Active

RF Industries

HEADER 6GHZ -55℃~+85℃ 50Ω COAXIAL CONNECTORS (RF) ROHS

Technical Specifications

Parameters and characteristics for this part

Specification	RFD-1687-4

Adapter Series	7/16 DIN, 4.3/10
Adapter Type	Plug to Jack
Body Finish	White Bronze
Body Material	Brass
Center Contact Material	Beryllium Copper
Center Contact Plating	Silver
Conversion Type	Between Series
Convert From (Adapter End)	4.3/10 Jack, Female Socket
Convert To (Adapter End)	Male Pin, 7/16 Plug
Dielectric Material	Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	6000 MHz
Impedance	50 Ohms
Insertion Loss	0.05 dB
Mating Cycles	500
Mounting Type	Free Hanging (In-Line)
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-55 °C
Style	Straight

HEADER 6GHZ -55℃~+85℃ 50Ω COAXIAL CONNECTORS (RF) ROHS

Part	Adapter Type	Style	Convert To (Adapter End)	Operating Temperature [Max]	Operating Temperature [Min]	Insertion Loss	Frequency - Max [Max]	Convert From (Adapter End)	Mounting Type	Dielectric Material	Mating Cycles	Body Material	Conversion Type	Body Finish	Adapter Series	Center Contact Plating	Impedance	Center Contact Material
RF Industries RFD-1687-4	Plug to Jack	Straight	7/16 Plug, Male Pin	85 °C	-55 °C	0.05 dB	6000 MHz	4.3/10 Jack, Female Socket	Free Hanging (In-Line)	Polytetrafluoroethylene (PTFE)	500	Brass	Between Series	White Bronze	4.3/10, 7/16 DIN	Silver	50 Ohms	Beryllium Copper

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Adapter Coaxial Connector 4.3/10 Jack, Female Socket To 7/16 Plug, Male Pin 50 Ohms
