PR81-15-24

Active

Polytron

DC DC CONVERTER +/-15V 2.25W

Search across all available documentation for this part.

Active

Polytron

DC DC CONVERTER +/-15V 2.25W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 249.00

General part information

Isolated Module DC DC Converter 2 Output 15V -15V 150mA, 150mA 21.6V - 26.4V Input

Technical documentation and resources

No documents available

Parameters and characteristics commom to parts in this series

DC DC CONVERTER +/-15V 2.25W

Part	Mounting Type	Package / Case	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Operating Temperature [Min]	Operating Temperature [Max]	Type	Power (Watts)	Current - Output (Max)	Current - Output (Max)	Voltage - Isolation	Number of Outputs	Voltage - Output 1	Voltage - Output 2	Efficiency	Voltage - Input (Min) [Min]	Voltage - Input (Max) [Max]	Applications
Polytron PR81-15-24	Through Hole	5-DIP Module	10.2 mm	50.8 mm	2 in	0.4 "	50.8 mm	2 in	-25 °C	71 °C	Isolated Module	2.25 W	150 mA	150 mA	500 V	2	15 V	-15 V	65 %	21.6 V	26.4 V	ITE (Commercial)
Polytron PR81-15C	Through Hole	5-DIP Module	10.2 mm	50.8 mm	2 in	0.4 "	50.8 mm	2 in	-25 °C	71 °C	Isolated Module	2.25 W	150 mA	150 mA	500 V	2	15 V	-15 V	65 %	4.5 V	5.5 V	ITE (Commercial)
