CRS1206AJW-100ELF

Active

Bourns Inc.

RES 10 OHM 5% 1/2W 1206

Search across all available documentation for this part.

Active

Bourns Inc.

RES 10 OHM 5% 1/2W 1206

Technical Specifications

Parameters and characteristics for this part

Specification	CRS1206AJW-100ELF

Composition	Thick Film
Features	Anti-Sulfur, Automotive AEC-Q200, Pulse Withstanding
Height - Seated (Max) [Max]	0.026 in
Height - Seated (Max) [Max]	0.65 mm
Number of Terminations	2
Operating Temperature [Max]	155 °C
Operating Temperature [Min]	-55 °C
Package / Case	1206 (3216 Metric)
Power (Watts)	0.5 W
Power (Watts)	0.5 W
Ratings	AEC-Q200
Resistance	10 Ohms
Size / Dimension [x]	3.1 mm
Size / Dimension [x]	0.122 "
Size / Dimension [y]	1.6 mm
Size / Dimension [y]	0.063 in
Supplier Device Package	1206
Temperature Coefficient	200 ppm/°C
Tolerance	5 %

Part	Operating Temperature [Max]	Operating Temperature [Min]	Temperature Coefficient	Resistance	Package / Case	Ratings	Number of Terminations	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Supplier Device Package	Composition	Features	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Tolerance	Power (Watts)	Power (Watts)
Bourns Inc. CRS1206AFX-5R10ELF	155 °C	-55 °C	100 ppm/°C	5.1 Ohms	1206 (3216 Metric)	AEC-Q200	2	0.026 in	0.65 mm	1206	Thick Film	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	1.6 mm	3.1 mm	0.063 in	0.122 "	1 %	0.5 W	0.5 W
Bourns Inc. CRS1206AJW-151ELF	155 °C	-55 °C	200 ppm/°C	150 Ohms	1206 (3216 Metric)	AEC-Q200	2	0.026 in	0.65 mm	1206	Thick Film	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	1.6 mm	3.1 mm	0.063 in	0.122 "	5 %	0.5 W	0.5 W
Bourns Inc. CRS1206AFX-2202ELF	155 °C	-55 °C	100 ppm/°C	22 kOhms	1206 (3216 Metric)	AEC-Q200	2	0.026 in	0.65 mm	1206	Thick Film	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	1.6 mm	3.1 mm	0.063 in	0.122 "	1 %	0.5 W	0.5 W
Bourns Inc. CRS1206AJW-100ELF	155 °C	-55 °C	200 ppm/°C	10 Ohms	1206 (3216 Metric)	AEC-Q200	2	0.026 in	0.65 mm	1206	Thick Film	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	1.6 mm	3.1 mm	0.063 in	0.122 "	5 %	0.5 W	0.5 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 Ohms ±5% 0.5W, 1/2W Chip Resistor 1206 (3216 Metric) Anti-Sulfur, Automotive AEC-Q200, Pulse Withstanding Thick Film
