MSAS-10PFFS-SF8002

Active

Amphenol LTW

M SERIES, M12, 1.5A, 10 PINS, RE

Search across all available documentation for this part.

Active

Amphenol LTW

M SERIES, M12, 1.5A, 10 PINS, RE

Technical Specifications

Parameters and characteristics for this part

Specification	MSAS-10PFFS-SF8002

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	1.5 A
Ingress Protection	IP68, IP69K
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Number of Positions	10
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	A
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	M12-10
Shielding	Shielded
Voltage Rating	30 VAC

Part	Mounting Feature	Contact Material	Shielding	Orientation	Shell Size - Insert	Shell Material	Color	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Insert Material	Voltage Rating	Primary Material	Ingress Protection	Number of Positions	Contact Finish - Mating	Current Rating (Amps)
Amphenol LTW MSAS-10PFFS-SF8001	Bulkhead - Front Side Nut	Copper Alloy	Shielded	A	M12-10	Glass Filled Nylon Polyamide (PA)	Black	Receptacle Female Sockets	-40 °C	105 ░C	Polyamide (PA) Nylon Glass Filled	30 VAC	Plastic	IP68 IP69K	10	Gold	1.5 A
Amphenol LTW MSAS-10PFFS-SF8002	Bulkhead - Front Side Nut	Copper Alloy	Shielded	A	M12-10	Glass Filled Nylon Polyamide (PA)	Black	Receptacle Female Sockets	-40 °C	105 ░C	Polyamide (PA) Nylon Glass Filled	30 VAC	Plastic	IP68 IP69K	10	Gold	1.5 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 Position Circular Connector Receptacle, Female Sockets Solder Cup
