6-2349952-4
ActiveTE Connectivity AMP Connectors
HEADERS & WIRE HOUSINGS HSG,REC,PANEL MOUNT, EP2.5,YELLOW, 4P
6-2349952-4
ActiveTE Connectivity AMP Connectors
HEADERS & WIRE HOUSINGS HSG,REC,PANEL MOUNT, EP2.5,YELLOW, 4P
Description
General part information
2349952 Series
Housing, Receptacle, Wire-to-Panel, 4 Position, 2.5 mm [.098 in] Centerline, Crimp, 1 Row, Yellow, Wire & Cable, Power & Signal, Economy Power 2.5
Technical Specifications
Parameters and characteristics for this part
| Specification | 6-2349952-4 |
|---|---|
| Color | Yellow |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Male Pin |
| Fastening Type | Latch Holder |
| Insulation Material | Nylon, Polyamide (PA) |
| Mounting Type | Panel Mount, Snap-In |
| Note | Contacts Not Included |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Pitch | 0.098 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
