SRP1206-3R3Z
ObsoleteBourns Inc.
FIXED IND 3.3UH 14A 7 MOHM SMD
Deep-Dive with AI
Search across all available documentation for this part.
SRP1206-3R3Z
ObsoleteBourns Inc.
FIXED IND 3.3UH 14A 7 MOHM SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SRP1206-3R3Z |
|---|---|
| Current Rating (Amps) | 14 A |
| Height - Seated (Max) [Max] | 0.236 in |
| Height - Seated (Max) [Max] | 6 mm |
| Inductance | 3.3 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension [x] | 0.492 in |
| Size / Dimension [x] | 12.5 mm |
| Size / Dimension [y] | 0.492 " |
| Size / Dimension [y] | 12.5 mm |
| Tolerance | 25 % |
| Type | Wirewound, Drum Core |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
SRP1206 Series
3.3 µH Shielded Drum Core, Wirewound Inductor 14 A 7mOhm Max Nonstandard
Documents
Technical documentation and resources
No documents available
